Part Description DIN right DIN left
STV-AV3-F2060 L79/65 A9 92/8 M2 RS/LS GR 5019405 5019406
STV-AV3-F2060 L79/65 A9 94/8 KABA M2 RS/LS MC 5016759 5016758
STV-AV3-F2060 L79/65 A9 92/10 M2 RS/LS MC 5006106 5006105
STV-AV3-F2060 L79/65 A9 92/10 M2 RS/LS GR 5012307 5012306
STV-AV3-F2060 L79/80 A9 94/8 KABA M2 RS/LS MC 5017285 5017286
STV-AV3-F2060 L79/80 A9 92/10 M2 RS/LS MC 5006108 5006107
STV-AV3-F2060 L79/80 A9 92/10 M2 RS/LS GR 5012305 5012304
STV-AV3-F2062 L79/40 A9 92/8 M2 RS/LS MC 5039366 5039367
STV-AV3-F2062 L79/45 A9 92/8 M2 RS/LS MC 5014400 5014368
STV-AV3-F2062 L79/45 A9 94/8 KABA M2 RS/LS MC 5038507 5038508
STV-AV3-F2062 L79/50 A9 92/8 M2 RS/LS MC 5030938 5030939
STV-AV3-F2062 L79/55 A9 92/8 M2 RS/LS MC 5015484 5015483
STV-AV3-F2062 L79/55 A9 92/8 M2 RS/LS GR 5020105 5020106
STV-AV3-F2062 L79/55 A9 92/10 M2 RS/LS MC 5014822 5014823
STV-AV3-F2062 L79/65 A9 94/8 KABA M2 RS/LS MC 5017300 5017301
STV-AV3-F2062 L79/65 A9 92/10 M2 RS/LS MC 5014958 5014959
STV-AV3-F2069 L79/45 A9 92/8 M2 RS/LS MC 5007999 5007998
STV-AV3-F2069 L79/45 A9 94/8 KABA M2 RS/LS MC 5038509 5038600
STV-AV3-F2069 L79/50 A9 92/8 M2 RS/LS MC 5030940 5030941
STV-AV3-F2069 L79/55 A9 92/8 M2 RS/LS MC 5008001 5008000
STV-AV3-F2069 L79/60 A9 92/10 M2 RS/LS MC 5008003 5008002
STV-AV3-F2069 L79/65 A9 94/8 KABA M2 RS/LS MC 5017307 5017308
STV-AV3-F2069 L79/65 A9 92/10 M2 RS/LS MC 5008010 5008009
STV-AV3-F2069 L79/65 A9 92/10 M2 RS/LS GR 5008006 5008004
STV-AV3-F2070 L79/35 A9 92/8 M2 RS/LS MC 5008189 5008188
STV-AV3-F2070 L79/45 A9 92/8 M2 RS/LS MC 5008185 5008184
STV-AV3-F2070 L79/55 A9 92/8 M2 RS/LS MC 5008187 5008186
STV-AV3-F2070 L79/55 A9 92/8 M2 RS/LS GR 5020103 5020104
STV-AV3-F2070 L79/55 A9 92/10 M2 RS/LS MC 5014952 5014953
STV-AV3-F2070 L79/65 A9 94/8 KABA M2 RS/LS MC 5024235 5024237
STV-AV3-F2070 L79/65 A9 92/10 M2 RS/LS MC 5006119 5006118
STV-AV3-F2070 L79/80 A9 94/8 KABA M2 RS/LS MC 5032121 5032122
STV-AV3-F20770 L79/50 A9 92/8 M2 RS/LS MC 5018509 5018521
STV-LB AV3-F2077062 L79/55 A9 92/8 M2 RS/LS MC 5034193 5034194
STV-LB AV3-F207769 L79/55 A9 92/8 M2 RS/LS MC 5034195 5034196
STV-AV3-F2460 L79/35 A9 92/8 M2 RS/LS MC 5006133 5006132
STV-AV3-F2460 L79/35 A9 92/8 M2 RS/LS GR 5006131 5006130
STV-AV3-F2460 L79/35 A9 92/8 M2 RS/LS EST 5020316 5020317
STV-AV3-F2460 L79/40 A9 92/8 M2 RS/LS MC 5007844 5007843
STV-AV3-F2460 L79/45 A9 92/8 M2 RS/LS MC 5007849 5007847
STV-AV3-F2460 L79/45 A9 94/8 KABA M2 RS/LS MC 5011505 5011504
STV-AV3-F2460 L79/45 A9 92/10 M2 RS/LS MC 5007846 5007845
STV-AV3-F2460 L79/50 A9 92/8 M2 RS/LS MC 5014939 5014940
STV-AV3-F2460 L79/55 A9 92/8 M2 RS/LS MC 5030628 5030629
STV-AV3-F2460 L79/65 A9 92/8 M2 RS/LS MC 5014881 5014880
