Winkhaus blueMatic EAV - Center Keep FRA; Magnetic Trigger for Center Keep FRA

blueMatic EAV 504474427Installation, Operating and
Maintenance Instructions
2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
Magnetic trigger for center keep FRA ... AV ...
Magnetic trigger for contact-free magnetic
release for autoLock AV3. Can be retrofitted in
center keeps FRA ... AV ... with magnet hole.
Center keep FRA ... AV ...
Center keep for latch and deadbolt for retro-
fitting of magnetic trigger and daytime latch
"TAFA". Designed for use with PVCu, Aluminum
and Timber/composite entrance doors.
Select the respective keeps according to the
profile systems in the current program manual
(see program overview keep - group 2).
T-G MAGNETAUSLÖSER  MV
AV

T-G MAGNETAUSLÖSER  MV
AV

T-G MAGNETAUSLÖSER  UMV
AV

T-G MAGNETAUSLÖSER 
UMV AV

