blueMatic EAV Installation, Operating and
Maintenance Instructions
The reader unit controls and monitors the access to the door.
• It is operated by means of transponder chips that work contactless.
• Hold a programmed transponder chip within (0 - 5 cm) of the antenna.
• Once the transponder chip is close enough to where it can read the
information, communication is established contact free.
• The transponder data is transmitted to the reader unit via the antenna.
• An acoustic signal at the reader unit will acknowledge the data transfer.
• The reader checks whether this transponder chip is authorized to access and
allows or denies access.
4.2 blueMatic EAV with Transponder
• After the enable time has elapsed, another fob can be recognized and
evaluated.
• If a transponder chip is unknown to the reader, it does not have access rights
and access will be denied.
Action Acoustic Signal Result
Door with transponder
chip Open
n n
short short
authorized
4.2.1 Operation
Action Acoustic Signal Result
Door with transponder
chip Open
n nnnnn
short long
not authorized
