3.7 Control of additional functions
A) Additional applications (only ekey home integra 2)
• The control of a additional application (e.g. garage door, alarm system) takes
place via the second relay of the integra 2.
• This potential-free signal can be used on the green/yellow wires on the
frame part T-KÜ-T1 RT KABEL 4 M or the signal cable from the frame power
supply T-NETZTEIL RAHM. 12 V DC 1,5 A (see figure 3.6.2-5/6, detail 2 
wires green/yellow).
B) Control of swing door opener (ekey home integra 1 resp. 2)
• When using a blueMatic EAV with control of the swing door drive, an
additional cable transition and frame part must be used.
(T-KÜ-T1 FT 3,5M, Part-no. 5040505; T-KÜ-T1 RT KABEL 4 M, Part-no.
5040503)
• Instead of the cable integra-EAV 3 m 3 the 3,5 m cable of the additional
cable transition (sash part) will be used.
• With this cable a connection is necessary between the motor housing EAV
(blue plug) and the control unit ekey home integra (length min. 2 m). To this
possibly disconnect the cable and remove the sheathing.
• Put the wire end sleeve at the wires white, brown and green and connect it
on terminal X6 according detail 1 (see Figure 3.6.2-5/6).
• Two remaining wires (yellow/grey) of the cable from the motor housing
have to be connected with the same colour at the wires (yellow/grey) of the
second cable transition = signal for swing door opener.
• If the cable was separated, connect it with wire connectors.
