Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMatic EAV Installation, Operating and
Maintenance Instructions
7 Technical specifications
7.2 Power supply (mounting on DIN rail)
Primary voltage: 100 - 240 V AC; 50/60 Hz
Secondary voltage: 12 V DC stabilized
Current: 2 A
Power: 24 W
Dimensions (H x B x T): 90 x 35 (= 2 TE) x 54,5 mm
Weight: approx. 0,3 kg
Installation: mounting on DIN rail
7.3 Frame power supply
Input: 230 V AC, 47-63 Hz, 0,6 A
Output: 12 V DC 1 A (2 A für 2 s)
Protection rating: IP 20
Temperature range: -20 °C bis +60 °C
Earthing of the door frame: Eyelet, screw connection with 4 x 15 mm
Dimensions: Frame part approx.24 x 260 x 33 mm (B x H x T)
Screw connection: max. 4 x 20 mm screws (max. length due to cable
routing!)
7.1 Motor housing EAV3
Voltage: 12 V DC stabilized, ± 1,0 V
Closed-circuit current: approx. 5 mA
max. current: approx. 1500 mA
Dimensions: 173 x 50 x 16 mm
Weight: approx. 380 g
Connection: Plug AMP Tyco, HE14, 6-pole, from Winkhaus
premanufactures
Configuration of wire: white – voltage, +12 V DC
brown – earth, 0 V
green – opening signal
yellow/grey – output signal for swing door
opener, only with motor housing EAV3 swing
door opener
Opening signal: min. 0,5 s
