Winkhaus blueMatic EAV - Page 35

Notice: You have to connect the following parts directly with
the door opener when using / connecting a door opener:
varistor at AC / free-wheeling diode at DC.
Reason: Protection of the relay from wear.
blueMatic EAV 504474435Installation, Operating and
Maintenance Instructions
2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
• 1 wireless receiver
(to be inserted in the flush-type box)
– mounting of the remote control receiver
on the inside
• 3 remote controls (programmed, color: dark
grey/grey)
• programming instruction + connection
diagram
Wireless remote control set
T-HT FUNK-FERNB F ANTHR
SET   
2410273
