blueMatic EAV Installation, Operating and
Maintenance Instructions
white   V DC
brown  V
green external opening signal
yellow
grey
pink (unscript)
Figure 3.6.2-1: Installation blueMatic EAV with Fingerprint ekey home micro
„Micro-Control unit, installed in the profile“ (sash side)
}
signal swing door
opener
yellowgrey  output signal swing door
opener (optional) only by
motor housing swing door
greenwhite  input for external poten-
tial-free contact (e g
unlocking via intercom
open button)
Notice! max  m extendable
(min  mm

)
Description Part-no.
Sash part cable transition
T-KÜ-T FT EKEY MICRO
(PLUS) M

Frame part cable transiti-
on T-KÜ-T RT Kabel M
for external power supply
mounting on DIN rail

Motor housing EAV for
retrofitting mechanical
locking system AV
standard

to ekey WH-EAV
Set Integra micro with App
ekey

ekey Adapter micro WH EAV WH
KÜ Y-connection from cable tran-
sition to motor housing and control
unit SE micro plugnplay
Fingerprint ekey home FS IN  T
BT  Decor element FS IN ED
Control unit ekey home SE micro 
ekey KAB A  m x  RJCP
Connection between fingerprint and
control unit
