Shadow 8 User Manual 1139300
Troubleshooting 4-3
Safety Output (OSSD) Faults
30 General safety output (OSSD) fault 1. Check wiring to see if OSSD 1
shorted to OSSD 2. Correct wiring if
necessary. See page 2-39.
2. Check wiring to see if OSSD 1 or
OSSD 2 shorted to power. Correct
wiring if necessary. See page 2-39.
3. Check wiring to see if OSSD 1 or
OSSD 2 shorted to ground. Correct
wiring if necessary. See page 2-39.
31 Safety outputs 1 and 2 are shorted
together.
Check and correct wiring of safety
outputs 1 and 2.
32 Safety output 1 shorted to power Check and correct wiring of safety
output 1.
33 Safety output 2 shorted to power Check and correct wiring of safety
output 2.
34 Safety output 1 shorted to ground Check and correct wiring of safety
output 1.
35 Safety output 2 shorted to ground Check and correct wiring of safety
output 2.
EDM Faults
40 General EDM fault. Possible incorrectly wired EDM circuit.
Check and correct wiring if necessary.
See page 2-41.
41 EDM circuit did not open before
transition to Machine Run state
Check and correct EDM wiring.
42 EDM circuit did not open after
transition to Machine Run state
Check and correct EDM wiring.
43 EDM circuit was in wrong state during
power-up
Check and correct EDM wiring.
44 EDM fault at power-up Check START input wire or EDM
function selection.
Controller Fault
50 Control logic fault Return receiver to Wintriss for repair.
Setup Error
60 Possible cross-talk. Check for possible cross-talk.
Segmentation (Extension) Faults
80 Configuration error Contact Wintriss Tech. Support.
81 Second segment error Check all cable connections. Contact
Wintriss Tech. Support.
82 Third segment error Check all cable connections. Contact
Wintriss Tech. Support.
83 Fourth segment error Check all cable connections. Contact
Wintriss Tech. Support.
85 Configuration error Contact Wintriss Tech. Support.
Table 4-1. Shadow 8 Fault Codes (Cont.)
Fault Code System Status Corrective Action
