1139300 Shadow 8 User Manual
4-4 Troubleshooting
86 Second segment firmware not
compatible with first segment
Replace with compatible component or
return system to Wintriss for upgrade.
87 Third segment firmware not compatible
with first segment
Replace with compatible component or
return system to Wintriss for upgrade.
88 Fourth segment firmware not
compatible with first segment
Replace with compatible component or
return system to Wintriss for upgrade.
90 Incorrect segment type in position two,
three, or four
Confirm that all segments are of the
same type, either all transmitters or all
receivers.
91 Segment 2 type does not match
segment 1 type
Confirm that segment 2 is the same
type (transmitter or receiver) as
segment 1.
92 Segment 3 type does not match
segment 1 type
Confirm that segment 3 is the same
type (transmitter or receiver) as
segment 1.
93 Segment 4 type does not match
segment 1 type
Confirm that segment 4 is the same
type (transmitter or receiver) as
segment 1.
95 Error in flex segment during operation Check connections. Contact Wintriss
Tech. Support.
96 Error in segment 2 during operation Check connections to segment 2.
Replace segment 2 with known good
segment. Contact Wintriss Tech.
Support.
97 Error in segment 3 during operation Check connections to segment 3.
Replace segment 3 with known good
segment. Contact Wintriss Tech.
Support.
98 Error in segment 4 during operation Check connections to segment 4.
Replace segment 4 with known good
segment. Contact Wintriss Tech.
Support.
100 Number of segments in system has
been reduced
Segment count is less than original
configuration. Add required
segment(s) or program system for
current configuration. See Removing
Extension Heads, page 2-60.
101 Too many flex nodes in the flexbus Make sure there are a total of only 4
segments.
Table 4-1. Shadow 8 Fault Codes (Cont.)
Fault Code System Status Corrective Action
