Wizard Z1 - Using the Pen Cartridge; Blades and Cartridges; Aborting a Cut

Using the Pen Cartridge
Changing the Pen in the Pen Cartridge
The pen cartridge is unlabeled and is black with a metal pen holder The pen cartridge is unlabeled and is black with a metal pen holder
column attached to the base. The pen icon within the software is a column attached to the base. The pen icon within the software is a
small stylus symbol.small stylus symbol.
1. Push the blade cartridge release down to eject the pen cartridge.1. Push the blade cartridge release down to eject the pen cartridge.
2. Turn the pen locking screw counter-clockwise to loosen it 2. Turn the pen locking screw counter-clockwise to loosen it
and slide the pen locking bolt away from the cartridge base.and slide the pen locking bolt away from the cartridge base.
3. Remove the existing pen by extracting it from the pen 3. Remove the existing pen by extracting it from the pen
holder.holder.
4. Replace with a new pen by placing the tip in rst and 4. Replace with a new pen by placing the tip in rst and
inserting the pen into the pen holder.inserting the pen into the pen holder.
5. Slide the pen locking bolt back into place and tighten 5. Slide the pen locking bolt back into place and tighten
the pen locking screw clockwise snug (do not overtighten the pen locking screw clockwise snug (do not overtighten
screw) to lock it into place.screw) to lock it into place.
6. Place the pen cartridge into the head. The pen holder 6. Place the pen cartridge into the head. The pen holder
should be to the right, with the pen tip facing toward the should be to the right, with the pen tip facing toward the
CMC.CMC.
7. Continue to the 7. Continue to the Install PenInstall Pen utility on the pen congurations tab. You may need to run this utility again if you utility on the pen congurations tab. You may need to run this utility again if you
change pen types.change pen types.
8. If the pen is not going to be used for a while, please remove it from the pen holder and replace the pen cap 8. If the pen is not going to be used for a while, please remove it from the pen holder and replace the pen cap
to keep it from drying out.to keep it from drying out.
Blades and Cartridges
See the FrameShop Getting Started Cartridge Manual at See the FrameShop Getting Started Cartridge Manual at https://wizardcutters.atlassian.net/wiki/x/7g4qYw https://wizardcutters.atlassian.net/wiki/x/7g4qYw
to nd additional information on the other cartridges and on changing the blades.to nd additional information on the other cartridges and on changing the blades.
Aborting a Cut
1. Hit the Emergency Stop button to abort the cut. You could also 1. Hit the Emergency Stop button to abort the cut. You could also
hit any key on the keyboard to abort the cut. Alternatively, hitting hit any key on the keyboard to abort the cut. Alternatively, hitting
the spacebar pauses the cut and gives option to abort.the spacebar pauses the cut and gives option to abort.
2. A prompt to click OK to release the motors will display. Click 2. A prompt to click OK to release the motors will display. Click
OK and the motors will immediately release.OK and the motors will immediately release.
3. Grasp the head and manually lower the head back to 3. Grasp the head and manually lower the head back to
the home position. the home position.
4. Pull out the Emergency Stop button and realign the 4. Pull out the Emergency Stop button and realign the
head. head. See “Homing and Alignment” page 19 for See “Homing and Alignment” page 19 for
instructions on how to Align the Head.instructions on how to Align the Head.
