Wizard Z1 - Head LED Behavior; LED Clamp Behavior

Head LED Behavior
State Color Intensity
No power to ECU. Off
Power to ECU, FrameShop not
communicating
White Solid
FrameShop communicating, Amber Solid
Head is being homed. Blue Blinking
Head is homed. Ready to cut. Green Solid
CMC is cutting Green Blinking
Waiting for a cartridge/blade change Green Solid
Depth is being changed. Purple Blinking
Error State. Red Solid
Emergency Stop Pressed Red Blinking
LED Clamp Behavior
Circumstance Clamp Color and Behavior
When ECU is powered up. The clamps LEDs will be green.
(Test Mode).
FrameShop startup. All clamp LEDs should turn
green.
Designing a mat. All clamp LEDs remain green.
Going to the Cut Preview screen. FrameShop verifies if the head
will hit a clamp. If the head will
traverse over a clamp, the LED
will turn red irrespective of the
clamp position. All other LEDs
will be green.
When the Cut button is pressed, or
the green Cut button on the CMC is
pressed.
The clamps are energized and
the position of the sensor is
read. If the sensor indicates that
the clamp is still engaged, then
that clamp's LED will flash red.
FrameShop verifies a second time
if the head will hit a clamp. Clamp is
rotated out of the cut area.
The flashing will cease and the
LED will turn green when the
user rotates the clamp to the
safe position.
