Care
58
2a
5a
5b
5c
> Open the lid of the brewer (2a).
> Release the brewing unit (5a).
> Pull the brewing unit (5b) upwards out of the brew chute. Use both the gripping lugs for pulling
it out (5c).
5d 5f
5g
5e
5h
5i
5
If it is diffi cult to remove the
brewer, the O-Rings must be
lubricated.
(“4.4.2 Lubricating O-Ring of
the Brewer Unit” on page 67)
5
