Technical data
81
8 Technical data
Power rating 1.7-2.3 kW
Mains power connection 1/N/PE ~ 50/60 Hz; 220 - 240 V
On site circuit protection maximum 16 A
Daily output 35 Cups
Coffee bean hopper 250 g
Variable brewing chamber 6 to 15 g
Capacity of water tank (without fi lter) 2.2 litres
Coffee grounds container approx. 15-20 portions
Height adjustable All-In-One spout with milk nozzle 67 to 141 mm
High-performance pump 15 bar
Independent heating systems 2
External dimensions Width 305 mm
Height 400 mm
Depth 443 mm
For maintenance and cleaning, at least 250 mm space
above the machine for dismantling
the brewer must be allowed.
Empty weight approximately. 15.0 kg
Weight of the brewer 1.2 kg
Cable length approximately 1.0 m
Continuous sound pressure level (Lpa) < 70 dB (A)
Machine type 03 0400
