Electric Cooktop -2
Installation Information
2-2
THIS APPLIANCE MUST BE PROPERLY GROUNDED AT ALL TIMES WHEN ELECTRICAL POWER IS APPLIED.
DO NOT GROUND THE APPLIANCE WITH THE NEUTRAL (WHITE) HOUSE SUPPLY WIRE. A SEPARATE
GROUND WIRE MUST BE UTILIZED.
IF ALUMINUM HOUSE SUPPLY WIRING IS UTILIZED, SPLICE THE APPLIANCE COPPER WIRE TO THE
ALUMINUM HOUSE WIRING USING SPECIAL CONNECTORS DESIGNED AND CERTIFIED FOR JOINING
COPPER AND ALUMINUM. FOLLOW THE CONNECTOR MANUFACTURES RECOMMENDED PROCEDURE
CAREFULLY. IMPROPER CONNECTION CAN RESULT IN A FIRE HAZARD.
PRE-INSTALLATION SPECIFICATIONS
This section of the manual covers some of the installation issues a service technician may need to know when servicing
a Wolf Electric Cooktop. If additional information is needed after reviewing this section of the manual, please refer to the
Installation Guide or contact the Wolf Appliance Customer Service Department.
Verify that power is disconnected from the electrical box before proceeding.
Electrical Requirements
Nominal Voltage
Model CT15E --------- 240 VAC / 50/60 Hz / 20 amp service
208 VAC / 60 Hz / 15 amp service
Model CT30E & EU - 240 VAC / 50/60 Hz / 40 amp service
208 VAC / 60 Hz / 40 amp service
Model CT30E-208 --- 208 VAC / 60 Hz / 40 amp service
Model CT36E & EU - 240 VAC / 50/60 Hz / 50 amp service
208 VAC / 60 Hz / 40 amp service
Maximum Connected Load
Model CT15E --------- 3.7 KW @ 240 VAC
2.8 KW @ 208 VAC
Model CT30E & EU - 8.1 KW @ 240 VAC
6.1 KW @ 208 VAC
Model CT30E-208 --- 7.9 KW @ 208 VAC
Model CT36E & EU - 10.5 KW @ 240 VAC
7.9 KW @ 208 VAC
The Wolf Electric Cooktops require a separate, grounded three-wire service with their own circuit breaker.
These appliances must be installed in accordance with National Electrical Codes, as well as all state, municipal and
local codes. The correct voltage, frequency and amperage must be supplied to the appliance from a dedicated,
grounded circuit which is protected by a properly sized circuit breaker or time delay fuse. The proper voltage, frequency
and amperage ratings are listed on the product rating plate.
Domestic cooktops are provided with a 48” (1219 mm) conduit consisting of two insulated hot lead conductors (copper)
and one insulated ground conductor (copper).
International units come with a terminal box and should be connected to the residential wiring with the hot leads
connected to positions 1 and 5. The residential ground lead should be connected to the position marked with the
ground symbol. (See Figure 2-1)
ICB Electrical Requirements
Required Power Supply
Model ICBCT15E ---- 220-240 VAC / 50/60 Hz / 20 amp
Model ICBCT30E ---- 220-240 VAC / 50/60 Hz / 40 amp
Model ICBCT30EU - 220-240 VAC / 50/60 Hz / 40 amp
Model ICBCT36E ---- 220-240 VAC / 50/60 Hz / 50 amp
Model ICBCT36EU - 220-240 VAC / 50/60 Hz / 50 amp
Maximum Connected Load
Model ICBCT15E --- 3.7 KW
Model ICBCT30E --- 8.1 KW @ 240 VAC
Model ICBCT30EU - 8.1 KW @ 240 VAC
Model ICBCT36E --- 10.5 KW @ 240 VAC
Model ICBCT36EU - 10.5 KW @ 240 VAC
