Electric Cooktop -2
Parts List w/Exploded Views
8-2
CT15E-2 PARTS LIST
Ref # Part # Description
1 811750 Glass and Keypad Assy. (Domestic)
811935 Glass and Keypad Assy. (International)
2 811773 Element, 2500 Watt
3 811768 Display Module
4 811771 Element, 1200 Watt
5 800511 Spring (Support)
7 811782 Seal, Silicone (Must be cut to size)
8 811731 Fan Assy. (15”)
10 811741 Power Module (15”)
11 811104 Terminal Box and Grnd Wire (International)
12 802709 Clamp-down Kit (Not all parts shown)
13 812686 Flex Conduit w/Terminal Block & Plate Assembly
Not Shown
Part # Description
811737 CT15E-2 Wire Harness
811740 Communication Cable
811745 Power Supply Cord
811746 Cooktop Fastener / Hardware Kit
