Set Point List
Name Min Value Max Value Initial Value Dimension
CONFIGURE MENU
1. Reverse Acting Act FALSE TRUE FALSE ---
2. No.1 Gear Teeth 50 120 62 ---
3. No.1 Max Hz 400 6000 700 Hz
4. Use No2 MPU FALSE TRUE TRUE ---
5. No.2 Gear Teeth 50 120 62 ---
6. No.2 Max Hz 400 6000 700 Hz
7.Normal Opn Minr Alm Ry FALSE TRUE FALSE ---
8.Normal Opn Mjor Alm Ry FALSE TRUE FALSE ---
SERVICE MENUS
Display 1
1. Engine Speed rpm
2. Speed Reference rpm
3. Generator Load KW
4. Actuator Output %
5. Fuel Limit Output %
Dynamics 1
1. Idle Prop. Gain1 0.001 50.0 1.0 ---
2. Rated Prop. Gain1 0.001 50.0 1.0 ---
3. Integrator Rate1 0.1 50.0 2.0 sec
4. Derivative Ratio1 1.0 100.0 5.0 ---
5. Window Width1 1.0 50.0 10.0 rpm
6. Gain Ratio1 0.1 10.0 1.0 ---
7. Gain Break Point 10.0 100.0 30.0 %
8. Gain Slope 0.1 10.0 1.0 ---
9. Speed Filter 20.0 0.1 15.0 Hz
Dynamics 2
1. Idle Prop. Gain2 0.001 50.0 1.0 ---
2. Rated Prop. Gain2 0.001 50.0 1.0 ---
3. Integrator Rate 2 0.1 50.0 2.0 sec
4. Derivative Ratio2 1.0 100.0 5.0 ---
5. Window Width2 1.0 50.0 10.0 rpm
6. Gain Ratio2 0.1 10.0 1.0 ---
