Manual 26004 721DSC for Marine Propulsion Application
Woodward
1
9
Name Min Value Max Value Initial Value Dimension
Speed Setting
1. Start Speed 200 1000 300 rpm
2. Idle Speed 200 1000 350 rpm
3. Rated Speed 300 1000 520 rpm
4. Raise Limit 300 1000 572 rpm
5. Raise/Lower Rate 0.1 100 1.0 rpm/sec
6. Load Transfer Rate 0.1 1000 1.0 rpm/sec
7. Spd Set at 4mA 200 1000 350 rpm
8. Spd Set at BP,mA 200 1000 8.0 mA
9. Spd Set at BP,RPM 200 1000 350 rpm
10. Spd Set at 20mA 200 1000 540 rpm
11. Tach at 4mA Output 0.0 1000 0.0 rpm
12 Tach at 20mA Output 0.0 1000 600 rpm
13. Speed Set at 4mA Output 0.0 1000 0.0 rpm
14. Speed Set at 20mA Output 0.0 1000 600 rpm
KW Setting
1. Rated KW 100 10000 1280 KW
2. 20mA KW Load Input 100 10000 1500 KW
3. KW Droop Set(%) 0.0 10.0 5.0 %
Fuel Limit
1. Start Fuel Limit 10.0 100.0 10.0 %
2. Torque Lmt P1,rpm 200 800 300 rpm
3. Torque Lmt P1,% 10.0 100.0 57.0 %
4. Torque Lmt P2,rpm 200 800 400 rpm
5. Torque Lmt P2,% 10.0 100.0 57.0 %
6. Torque Lmt P3,rpm 200 800 468 rpm
7. Torque Lmt P3,% 10.0 100.0 83.0 %
8. Torque Lmt P4,rpm 200 800 520 rpm
9. Torque Lmt P4,% 10.0 100.0 87.0 %
10. Maximum Fuel Limit 50.0 100.0 87.0 %
