Woodward 721 - Set Point Record Sheets

Manual 26004 721DSC for Marine Propulsion Application
Woodward
3
7
WOODWARD GOVERNOR COMPANY
ENGINE CONTROLS DIVISION
721 DIGITAL ENGINE CONTROL
FOR KAWASAKI HEAVY INDUSTRIES, LTD.
SYSTEM 9907-717
======================================================================
C.C1
∗ CONFIGURE MENU ∗
1 Reverse Acting Act #FALSE (TRUE, FALSE) _________
2 No.1 Gear Teeth #62 (50, 120) _________
3 No.1 Max Hz #700 (400, 6000) _________
4 Use No2 MPU #TRUE (TRUE, FALSE) _________
5 No.2 Gear Teeth #62 (50, 120) _________
6 No.2 Max Hz #700 (400, 6000) _________
7 Normal Opn Minr Alm Ry #FALSE (TRUE, FALSE) _________
8 Normal Opn Mjr Alm Ry #FALSE (TRUE, FALSE) _________
======================================================================
S.S1
∗ Display 1 ∗
1 Engine Speed _________
2 Speed Reference _________
3 Generator Load _________
4 Actuator Output _________
5 Fuel Limit Output _________
======================================================================
S.S2
∗ Dynamics 1 ∗
1 Idle Prop. Gain1 ∗1.0 (0.001, 50.0) _________
2 Rated Prop. Gain1 ∗1.0 (0.001, 50.0) _________
3 Integrator Rate1 ∗2.0 (0.1, 50.0) _________
4 Derivative Ratio1 ∗5.0 (1.0, 100.0) _________
5 Window Width1 ∗10.0 (1.0, 50.0) _________
6 Gain Ratio1 ∗1.0 (0.1, 10.0) _________
7 Gain Break Point ∗30.0 (10.0, 100.0) _________
8 Gain Slope ∗1.0 (0.1, 10.0) _________
9 Speed Filter ∗15.0 (0.1, 20.0) _________
