13. Speed Set at 4mA Output
Set this set point to the speed reference value in RPM when the Speed Reference output
channel outputs 4 mA.
14. Speed Set at 20mA Output
Set this set point to the speed reference value in RPM when the Speed Reference output
channel outputs 20 mA.
KW Settings
KW Setting Menus are set point menus for setting engine load set points.
1. Rated KW
Rated KW is the generator’s rated output.
2. 20mA KW Load Input
20mA KW Load Input is the KW load level when the KW transducer input signal
(connected to terminal 36 and 37) is 20 mA.
3. KW Droop Set (%)
KW Droop is the rate at which the engine speed droops based on the KW transducer
input signal which varies from no load to full load. The actual droop is dependent on
linkage adjustment and stroke. For example, 5% droop gives a real droop of 2.5% if the
control output changes 50% from no load to full load.
Fuel Limit
Fuel Limiters limit the actuator output current from the control.
1. Start Fuel Limit
Start Fuel Limit sets the maximum actuator output current for starting the engine. Set
this set point to the fuel supply level necessary to start the engine.
2. Torque Lmt P1, rpm
Torque Lmt P1, rpm is the engine speed in RPM at the first torque limit.
3. Torque Lmt P1, %
Torque Lmt P1, % is the maximum actuator output current in percent at the first torque
limit.
4. Torque Lmt P2, rpm
Torque Lmt P2, rpm is the engine speed in RPM at the second torque limit.
5. Torque Lmt P2, %
Torque Lmt P2, % is the maximum actuator output current in percent at the second
torque limit.
6. Torque Lmt P3, rpm
Torque Lmt P3, rpm is the engine speed in RPM at the third torque limit.
