10. Contact F Status
Contact F Status displays the status of the Tie Circuit Breaker Aux. (TCB AUX) contact
(open or closed).
11. Contact G Status
Contact G Status displays the status of the SHAFT GENERATOR OPERATION MODE
selection contact (open or closed).
12. Contact H Status
Contact H Status displays the status of the MAIN SHAFT CLUTCH ON contact (open
or closed).
13. Major Alarm Ry Status
Major Alarm Ry Status indicates if a major alarm has been issued or not (open or closed).
14. Minor Alarm Ry Status
Minor Alarm Ry Status indicates if a minor alarm has been issued or not (open or closed).
15. Transfer Mode Ry Status
Transfer Mode Ry Status indicates if the engine is transferring load or not (open or
closed).
16. #1 LED Status
#1 LED Status displays the status of #1 LED (on or off).
17. #2 LED Status
#2 LED Status displays the status of #2 LED (on or off).
Alarms
These are menus to monitor fault status.
1. Minor Alarm
Minor Alarm displays “TRUE” if the control has detected any minor alarm.
2. Major Alarm
Major Alarm displays “TRUE” if the control has detected the major alarm.
3. No.1 MPU Failure
No.1 MPU Failure displays “TRUE” if MPU #1 has failed.
4. No.2 MPU Failure
No.2 MPU Failure displays “TRUE” if MPU #2 has failed.
5. KW Signal Fail
KW Signal Fail displays “TRUE” if the 4-20 mA KW transducer signal has failed.
6. Spd Set Signal Fail
Spd Set Signal Fail displays “TRUE” if the 4-20 mA remote speed setting signal has
failed.
