Name Min Value Max Value Initial Value Dimension
Display 2
1. Speed Signal #1 rpm
2. Speed Signal #2 rpm
3. Kw Signal Input,% %
4. Spd set Input,mA mA
5. Contact A Status
6. Contact B Status
7. Contact C Status
8. Contact D Status
9. Contact E Status
10. Contact F Status
11. Contact G Status
12. Contact H Status
13. Major Alarm Ry Status
14. Minor Alarm Ry Status
15. Transfer Mode Ry Status
16. #1 LED Status
17. #2 LED Status
Alarms
1. Minor Alarm
2. Major Alarm
3. No1 MPU Failure
4. No2 MPU Failure
5. KW Signal Fail
6. Spd Set Signal Fail
7. Fault Reset FALSE TRUE FALSE ---
CAUTION
To prevent possible damage to the engine resulting from improper control
settings, make sure you save the set points before removing power from
the control. Failure to save the set points before removing power from the
control causes them to revert to the previously saved settings.
