Appliance information
Greenstar Heatslave II
ErP -
6 720 813 344 (2014/09) 9
Legend:
A
[1] CONTROL BOX ASSEMBLY
[2] SERVICE MODE BUTTON
[3] CH TEMPERATURE CONTROL KNOB
[4] LCD DISPLAY
[5] CASING SIDE PANEL
[6] FLUE "KNOCK-OUT" SECTION
[7] TANK TEMPERATURE CONTROL KNOB
[8] DIAGNOSIS PORT - WORCESTER ENGINEER
[9] SYSTEM PRESSURE GAUGE
[10] FLUE GAS SAMPLING POINT
[11] FLUE MANIFOLD COVER
[12] FLUE OVERHEAT THERMOSTAT PHIAL
[13] AIR INLET CASING FLEXIBLE AIR DUCT
(CONNECTING TO AIR INTAKE ON BURNER)
[14] CASING SUPPORT BRACKET
[15] SECONDARY HEAT EXCHANGER DRAIN
[16] HEAT EXCHANGER FLOW PIPE
[17] CONDENSATE OUTLET
[18] CONDENSATE TRAP
[19] CONDENSATE DRAIN PIPE
[20] FLEXIBLE CONDENSATE DRAIN PIPE CONNECTION
[21] PRIMARY HEAT EXCHANGER
[22] OIL ISOLATING VALVE
[23] BASE PLATE AND OIL DRIP TRAY
[24] COMBUSTION CHAMBER ACCESS DOOR AND ONE PIECE
BAFFLE SET LOCATION
[25] PRIMARY HEAT EXCHANGER DRAIN
[26] EXPANSION VESSEL
[27] EXPANSION VESSEL BRACKET
[28] RIELLO RDB 2.2 BURNER
[29] HEATSLAVE TANK
[30] HEATSLAVE TANK DRAIN
[a] OPTIONAL FASCIA MOUNTED PROGRAMMERS AVAILABLE
(not supplied with the appliance)
B
[31] CIRCULATING PUMP
[32] MANUAL RESET TANK OVERHEAT THERMOSTAT
[33] DRAIN POINT
[34] DIVERTER VALVE ASSEMBLY
[35] AUTOMATIC AIR VENT
C
[36] DHW FLOW TURBINE
[37] TANK TEMPERATURE SENSOR (NTC)
[38] DHW HEAT EXCHANGER
[39] MAINS INLET TEMPERATURE SENSOR (NTC)
[40] DHW PRESSURE RELIEF VALVE
[41] DHW TEMPERATURE SENSOR (NTC)
[42] PRIMARY MANUAL AIR VENT
[43] FLOW TEMPERATURE SENSOR (NTC)
[44] PRIMARY HEAT EXCHANGER SAFETY SENSOR (NTC)
[45] SECONDARY HEAT EXCHANGER MANUAL AIR VENT
[46] SECONDARY HEAT EXCHANGER
[47] SECONDARY HEAT EXCHANGER MANUAL AIR VENT
[48] PRESSURE RELIEF VALVE
All the following Pre-Installation sections must be read
and requirements met before starting boiler or flue
installation.
CAUTION: Isolate the mains supplies before starting any
work and observe all relevant safety precautions.
