Satellite Upconverter Manual WORK Microwave
29 / 49 V151207
3.5.5 STATUS
3.5.5.1 CONVERTER STATUS
The item “STATUS” in the main menu allows access to display the current alarm status of the Converter.
After pressing “ENTER” the bit map for the alarm status is displayed on the top display line with an 8 charac-
ters (32 Bit) long hex number. The status is updated by pressing “ENTER”. Active alarms and warnings are
shown as plain text when pressing the “Left” and “Right” arrow keys.
The bit map for the status hex number is as follows:
Bit
Status
Bit
Status
31
-
15
-
30
Output off
14
-
29
External mute
13
-
28
-
12
-
27
-
11
-
26
-
10
-
25
Local Mode
9
-
24
External reference source
8
-
23
-
7
-
22
-
6
-
21
-
5
-
20
Synthesizer alarm
4
-
19
MW output module alarm
3
-
18
Amplifier module alarm
2
-
17
Reference alarm
1
-
16
Internal module alarm
0
OCXO Oven Cold Warning
3.5.5.2 SYSTEM STATUS
The system status submenu displays general device status bits.
Bit
Status
Bit
Status
31
Summary alarm
15
-
30
-
14
-
29
-
13
-
28
-
12
-
27
Messagebus warning
11
-
26
Webctl warning
10
-
25
-
9
-
24
Webserver warning
8
-
23
Temperature low warning
7
-
22
Temperature high warning
6
Local mode active
21
EEPROM warning
5
Remote mode active
20
Ethernet warning
4
Alarm relay disabled
19
Display warning
3
Alarm relay test
18
Real time clock warning
2
External mute input warning
17
Keyboard warning
1
-
16
Temperature sensor warning
0
Mod. Communication alarm
