4.7.1 SNMP OID Table
The base OID is 1.3.6.1.4.1.29890.1. This Base ID is identical for all WORK Microwave devices and has to
be combined with the OID in the table below.
For example, to set the attenuation the entire OID is: 1.3.6.1.4.1.29890.1.5.3.1.1.3.
MIB Identifier
OID
Description
conv2OutputCh1
.5.3.1.1.1
Sets and reads the output
conv2FrequencyCh1
.5.3.1.1.2
Sets and reads the RF frequency
conv2AttenuationCh1
.5.3.1.1.3
Sets and reads the attenuation
conv2EqualizerCh1
.5.3.1.1.4
Sets and reads the equalization
conv2IFreqCh1
.5.3.1.1.5
Sets and reads the IF (option 70/140 MHz)
conv2AttenuationCh2
.5.3.1.2.3
Sets and reads the attenuation (channel 2)
conv2EqualizerCh2
.5.3.1.2.4
Sets and reads the equalization (channel 2)
conv2ReferenceSource
.5.3.1.10
Sets and reads the reference source
conv2MCMultipointAddress
.5.3.2.1.1
Sets and reads the multipoint command address
conv2MCInterfaceType
.5.3.2.1.2
Sets and reads the serial interface type
conv2MCRS485TXTermination
.5.3.2.1.3
Sets and reads the RS485 TX termination
conv2MCRS485RXTermination
.5.3.2.1.4
Sets and reads the RS485 RX termination
conv2MCPacketDelay
.5.3.2.1.5
Sets and reads the packet delay
conv2MCBaudRate
.5.3.2.1.6
Sets and reads the serial baud rate
conv2MCConfiguration
.5.3.2.1.7
Sets and reads the serial configuration
conv2MCIPAddress
.5.3.2.1.8
Sets and reads the IP address
conv2MCSubnetMask
.5.3.2.1.9
Sets and reads the subnet mask
conv2MCGateway
.5.3.2.1.10
Sets and reads the gateway address
conv2MCTCPPort
.5.3.2.1.11
Sets and reads the TCP port number
conv2MCUDPPort
.5.3.2.1.12
Sets and reads the UDP port number
conv2LoadDeviceState
.5.3.2.2
Loads a stored device state
conv2SaveDeviceState
.5.3.2.3
Saves a device state
conv2Autosave
.5.3.2.4
Sets and reads the “auto save” function
conv2MinFrequency
.5.3.2.5
Sets and reads the minimum frequency
conv2MaxFrequency
.5.3.2.6
Sets and reads the maximum frequency
conv2FrequencyOffset
.5.3.2.7
Sets and reads the offset frequency
conv2RemoteLocal
.5.3.2.8
Sets and reads the local/remote mode
conv2OnOffKeyFunction
.5.3.2.9
Sets and reads the On/Off key function
conv2ExternalMuteInput
.5.3.2.10
Sets and reads the external mute input
conv2AlarmRelay
.5.3.2.11
Sets and reads the alarm relay
conv2BacklightMode
.5.3.2.12
Sets and reads the display backlight mode
conv2DTTime
.5.3.2.20.1
Sets and reads the time
conv2DTDate
.5.3.2.20.2
Sets and reads the date
conv2DTDateNum
.5.3.2.20.3
Sets and reads the date (numerical format)
conv2DTTimeZone
.5.3.2.20.4
Sets and reads the time zone
conv2DTNTPOperation
.5.3.2.20.5
Sets and reads the NTP time operation
conv2DTNTInterval
.5.3.2.20.6
Sets and reads the NTP sync. interval
conv2DTNTPServer
.5.3.2.20.7
Sets and reads the NTP server IP address
conv2DTNTPBackupServer
.5.3.2.20.8
Sets and reads the NTP backup server IP address
conv2BannerMode
.5.3.2.22
Sets and reads the banner mode
conv2Banner
.5.3.2.23
Sets and reads the device banner text
conv2SerialNumber
.5.3.2.30
Reads the device serial number
conv2BaseSystemID
.5.3.2.50.1
Reads the base system firmware ID
conv2DeviceID
.5.3.2.50.2
Reads the device firmware ID
