Satellite Upconverter Manual WORK Microwave
34 / 49 V151207
ID
Firmware Identification
Strings
(The
opcode
‘VW’ is due
to compatibility re
a
sons)
ID-No, None
{AID}) Front panel device ID
{AID0}9
Front panel device ID
{AID1}:
Base system ID
{AID2};
Interface module ID
{AID3}<
OCXO reference module ID
{AID4}=
Synthesizer module ID
{AID5}>
IF module ID
{AI
D6}? reserved
VW
VF
Front Panel Firmware
Identification String
.
Equal to (‘ID0’)
(The opcode ‘VF’ is due
to compatibility reasons)
None
{AVF}8
ZO
Auto Save Mode
(The opcode ‘O’ is due to
compatibility reasons)
0, 1, ?
{AZO0}U Autosave Off
{A
ZO1}V Autosave On
{A
ZO?}d
O
S
Save Settings
00 to 15
{AS03}2
R
Load and Set Settings
00 to 15
{AR01}/
ZA
MULTIPOINT Addr.
(The opcode ‘DA’ is due
to compatibility reasons)
64 to 90 (‘@’ to ‘Z’)
{AZA66}c Set to MPT address ‘B’
{A
ZA?}V
DA
ZR
Configure the Serial Con-
trol Inte
rface (see
Figure
14)
0 to 256, ? (see de-
tailed descri
ption)
{AZR101}z set configuration
{AZR?}g
read value
ZC
Configuration Byte
(see Figure 16)
0 to 127
{AZC004}m
{AZC?}X
ZI
IP Address
IP addr, ?, none
{AZI192.168.011.111}, set IP address
{AZI?}^
read IP address
{AZI}? read IP address
ZB
IP Subnet Mask
ZU mask, ?, none
{AZB255.255.255.000}) set IP mask
{AZB}8
read IP mask
{AZB?}W read IP mask
ZW
IP Gateway
ZW addr, ?, none
{AZW192.168.002.001}8 set IP gateway addr.
{AZW}M
read IP gateway addr.
{AZW?}l read IP gateway addr.
ZP
TCP Port
ZP number, ?, none
{AZP50505}F set TCP port number
{AZP}F
read TCP port number
{AZP?}e read TCP port number
ZT
Set/Get Time
Timecode (hhmm), ?
{AZT1035}4 sets clock to 10:35
{AZT?}I
read time
Response:
{AZT175148} time in hhmmss
ZD
Set/Get Date
Datecode
(yyyymmdd), ?
{AZD20050429}q set date
{AZD?}Y
read date
ZG
External Mute Input
(The opcode ‘G’ is due to
compatibil
ity reasons)
0, 1, ?
{AZG0}M disable ext. mute input
{A
ZG1}N enable ext. mute input
{A
ZG?}\
G
ZJ
Alarm Relay Inhibit
(The opcode ‘J’ is due to
compatibility reasons)
0, 1, ?
{AZJ0}P Alarm relay disabled
{A
ZJ1}Q Alarm relay enabled
{A
ZJ?}_
J
ZF
Factory reset (see
3.5.3.17)
None
{AZF}<
