Satellite Upconverter Manual WORK Microwave
37 / 49 V151207
No
Event
No
Event
0
Power Up
6
ext. muting off
1
-
7
-
2
Oven warm
8
-
3
Output off
9
set to internal reference
4
Output on
10
set to external reference
5
ext. muting on
Figure 15: Events for Command EE
Figure 16: Configuration byte for Command ZC
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
reserved
reserved
reserved
reserved
reserved
Interface
Send Delay
Interface Send Delay:
These bits set the transmission delay of the serial interfaces. The answer on a re
ceived
command can be delayed. This is helpful for two wire bus systems, where without addi-
tional
delay collisions between a still active master device and an already active slave
device may occur. The basic delay depends on the baud rate and is approx. 3 ms for
19200 baud. Possible additional delays are:
Bit 1
Bit 0
Delay
0
0
0 ms
0
1
20 ms
1
0
40 ms
1
1
80 ms
