Woson TANDA - 4.6 Specification

Steam Sterilizer Operation Manual
TANDA Model REV-E Page of 43
15
4.2 Rear View
No.
Name
Description
8
Power socket
Connected with power source
9
Printer out port
Connect a mini printer and output sterilization record
10
Relief Valve
Leak pressure automatically when over working pressure
11
Nameplate
Basic information of manufacturer
12
Vent area
Output heat from this vent area by condenser
4.3 Open View
No.
Name
Description
13
Air Filter
Filter the air and ensure air into chamber is clean
14
Door Seal
For sealing the door
15
Water level sensor
For used water tank
16
Tray & Rack
To load the articles
