Xerox DocuMate 3125 User Manual

Xerox DocuMate 3125
User’s Guide
176
3. The replaceable roller is located behind the paper guides.
4. The roller is held in place with a lock tab that rotates to lock and unlock it. To unlock the tab, rotate it upward
until the small lock flange is completely free.
5. Remove the roller from the scanner and discard it, it cannot be repaired.
6. Before installing the new roller, clean any dust that may have gotten on it during shipping.
7. Insert the left end of the new roller assembly into the hole in the ADF cover. Angle the roller into the scanner
and align the lock tab with the slot in the scanner.

Xerox DocuMate 3125 Specifications

General

Grayscale levels	8
Maximum scan area (ADF)	216 x 965 mm
Minimum scan area (ADF)	51 x 74 mm
Cables included	AC, USB
Built-in display	No
USB port	Yes
USB version	2.0
