June 2014
2-10
Xerox® Phaser® 3052/3260 Service Manual
08-700 , 08-600
Status Indicator RAPs
08-700 Output Tray Full Fault
The Output Tray Full Sensor has detected that the Output Tray is full.
BSD-Reference: 10.2 Print Exit
Initial Actions
Remove sheets from the Output Tray. (Maximum capacity is 250 sheets/ standard paper 8.5 x
11 in./ 80g/m2.)
Procedure
Enter Diagnostic (EDC) Mode. Select: [DC330 Test Routines, 101-Clutch, Out Bin Full] to
block and clear the Out Bin Full Sensor. The signal changes.
YN
Check that the sensor connector is firmly seated.
Check that there is no contamination present.
Check for an open or short circuit.
Replace the Output Tray Full Sensor, (REP 1.20), PL 4.3.
Check actuator for binding. If the problem is intermittent, replace the Out Bin Full Sensor Actu-
ator, (REP 1.20), PL 4.3.
08-600 Paper Jam in Duplex Area Fault
The machine has detected a paper jam in the Duplex Area.
BSD-Reference: 10.2 Print Exit
Initial Actions
Remove jammed sheets from duplex area. Refer to Section 7: Troubleshooting, in the Xerox®
Phaser® 3052/3260 User Guide for detailed instructions on clearing paper jams.
Ensure that the paper guide and machine settings are correct for the paper that is loaded in the
tray.
Procedure
Check the Exit Sensor Actuator. The actuator moves freely.
YN
Replace the Exit Sensor Actuator, (REP 1.19), PL 4.1.
Enter Diagnostics (EDC) Mode. Select: [DC330 Test Routines, 102-Sensor, Exit Sens] to
block and clear the Exit Sensor. The sensor is OK.
YN
Check that the sensor connector is firmly seated
Check that there is no contamination present.
Check for an open or short circuit.
Replace the Exit Sensor (REP 1.19), PL 4.1.
Check the following parts for wear or damage and replace if needed:
Duplex Paper Guide (REP 1.18), PL 4.2
Duplex Gate PL 4.2
Duplex Gate Spring PL 4.2
Duplex Gate Mounting PL 4.2
Paper Guide on Rear Cover [PL 1.2]
Make certain that the Duplex Gate is seated correctly and moves freely without binding.PL
