Cleaning the Printer
Phaser® 4510 Laser Printer
5-4
4. Reinsert the feed roll on the paper tray shaft.
5. Align the tabs on the feed roll with the slots on the shaft (1), and then push the feed roll
completely onto the shaft (2).
6. Push the paper tray back into the printer.
1
2
4510-118
4510-044
