Troubleshooting
Phaser 6700 Color Printer 115
User Guide
The following illustration shows where paper jams can occur along the paper path in the printer
configured with the optional trays and Finisher.
1. 1100-Sheet High-Capacity Feeder
2. 550-Sheet Feeders
3. Tray 2
4. Horizontal Transport Unit
5. Finisher
6. Fuser
7. Right Side Door
8. Duplex Unit
9. Tray 1
10. Optional Feeder Right Side Doors
CAUTION: Do not attempt to clear any paper jams using tools or instruments. This can permanently
damage the printer.
