Xerox VersaLink C505S - Height Configurations for Optional Feeders and Cabinet with Casters; Height Configurations for Optional High-Capacity Feeder (HCF) with Casters; Total Space Requirements

Height Configurations for Optional Feeders and Cabinet with Casters
2 Optional Feeders1 Optional FeederNo Optional FeedersItem
Configuration View
122.6 cm (48.3 in.)110.3 cm (43.4 in.)98.0 cm (38.6 in.)Height (mm)
113.0 cm (44.5 in.)100.7 cm (39.6 in.)88.4 cm (34.8 in.)Document Glass
Height
Height Configurations for Optional High-Capacity Feeder (HCF) with
Casters
1 Optional FeederNo Optional FeedersItem
Configuration View
122.6 cm (48.3 in.)110.3 cm (43.4 in.)Height
113. mm (44.5 in.)100.7 cm (39.7 in.)Document Glass Height
Total Space Requirements
Configurations without OptionsDimension
87.0 cm (34.3 in.)Width
132.2 cm (52.0 in.)Depth
87.8 cm (34.6 in.)Height
Xerox
®
VersaLink
®
C505 Multifunction PrinterA-6
User Guide
Specifications
