Xerox VersaLink C505S - Power Options

DescriptionNameItem
Near Field Communication (NFC) is a technology that enables
devices to communicate when they are within 10 cm (4 in.) of
each other. Use the NFC area to obtain a network interface or
to establish a TCP/IP connection between your device and the
printer.
NFC Area5
This light blinks blue or amber to indicate printer status.Status LED6
• Blue
- Blinks once slowy to acknowledge a successful Authentic-
ation request.
- Blinks once slowly for a Copy or Print job initiated at the
control panel.
- Blinks twice slowly for Fax or Print job received from the
network.
- Blinks fast while the printer is powering up, or to signal
detection of a Wi-Fi Direct connection request.
• Amber
- Blinks to indicate an error condition or warning that re-
quires your attention. For example, an out-of-toner con-
dition, a paper jam, or out of paper for the current job.
- The printer status LED also blinks to indicate a system
error, which typically is associated with an error code.
Power Options
The printer has a single multifunction button on the control panel.
• When used in conjunction with the power switch, the Power/Wake button powers on
the printer.
• If the printer is already powered on, the Power/Wake button can be used to:
- restart the printer
- enter or exit Sleep mode
- enter or exit Low-Power mode
• The Power/Wake button also flashes when the printer is in low-power mode.
