Clearance Requirements
Clearance Requirements for Standard Configuration
Environmental Specifications
Temperature
• Operating Temperature Range: 10–32°C (50–90°F)
• Optimal Temperature Range: 15–28°C (59–82°F)
Relative Humidity
• Operating Humidity Range: 10–85%
• Optimal Humidity Range: 20–70% relative humidity at 28°C (82°F)
Note
Under extreme environmental conditions, such as 10°C and 85% relative humidity,
printing defects can occur due to condensation inside the printer.
Elevation
For optimum performance, use the printer at elevations below 3100 m (10,170 ft.).
Electrical Specifications
Power Supply Voltage and Frequency
Current RequiredFrequencyPower Supply Voltage
12 A60 Hz +/-3 Hz120 VAC +/-10%
(108–132 VAC)
A-7Xerox
®
VersaLink
®
C505 Multifunction Printer
User Guide
Specifications
