1. Horizontal Transport Unit (Center Tray)
2. Finisher Front Cover
3. Right Top Tray
4. Right Middle Tray
5. Staple Cartridge
6. Booklet Maker Tray (Right Bottom Tray)
7. Booklet Staple Unit
8. Booklet Maker Unit
CCoonnttrrooll PPaanneell
The control panel consists of a touch screen and buttons that you press to control the functions
available on the printer. The control panel:
• Displays the current operating status of the printer.
• Provides access to printing features.
• Provides access to reference materials.
• Provides access to Tools and Setup menus.
• Prompts you to load paper, replace supplies, and clear jams.
• Displays errors and warnings.
• Provides the Power/Wake button used for powering on or off the printer. This button also supports
the power-saver modes, and blinks to indicate the power status of the printer.
Item Name
Description
1 NFC Area
(Optional)
Near Field Communication (NFC), is a technology that enables
devices to communicate when they are within 10 cm (4 in.) of
each other. Use the NFC area to obtain a network interface or to
establish a TCP/IP connection between your device and the
printer.
Note: The indicator is visible when NFC is activated.
2 Home Button This button provides access to the Home menu for access to
printer features.
Xerox
®
VersaLink
®
C8000/C9000 Color Printer
User Guide
23
Getting Started
