June 2014
vi
Xerox® WorkCentre® 3025 Multifunction Printer Service Manual
Reference Symbology
Introduction
Reference Symbology
The following reference symbols are used throughout the Xerox® WorkCentre® 3025 Printer
Service Documentation.
1. Flag
• This symbol indicates a reference point into a circuit diagram from a RAP.
2. Note
• This symbol is used to refer to notes that are found on the same page of a circuit dia-
gram. A note is used whenever it is necessary to highlight an operating or mainte-
nance procedure, a practice, condition, or statement.
• Hints or other information that may assist the user.
3. Parts List
• This symbol, example (PL2.1), refers to the Parts List exploded view page where the
part can be found.
4. Adjustment
• This symbol refers to an adjustment procedure in the Repair/Adjustments section.
5. Test Point, Test Hole, Test Stake
• This symbol is used to indicate that a test point, test hole, or test stake is available
for accessing the signal line. The prefix indicates whether the access is a test point
(TP), test hole (TH), or test stake (TS).
6. Commoning Point
• This symbol is used to refer to a location in the machine wiring where more than two
wires a connected together at a single point.
7. Arrow
• This symbol points to the location to install, gain access to, or to release a compo-
nent.
Safety Symbols and Terminology
The following are examples of the terminology and symbols that are used in this documenta-
tion for an Electrostatic Device Caution, Laser Warning, and general Warnings, Cautions, or
Notes.
WARNING
Improper operation may result in injury to a person.
CAUTION
Improper operation may result in machine damage.
Laser
Indicates that Laser safety precautions must be used.
Hot Surface
Indicates that a surface can be hot. Use caution when reaching in the machine to avoid touch-
ing the hot surface.
To Next Page
