Xerox WorkCentre 3025BI Service Manual

June 2014
3-7
Xerox® WorkCentre® 3025 Multifunction Printer Service Manual
IQ6, IQ7
Image Quality
Figure 1 Dark or Black Image
IQ7 Uneven Density RAP
Print density is uneven between the left and right portion of the printed image (Figure 1).
Initial Actions
• Ensure that the printer is level.
• Remove the Print Cartridge. Rotate the Print Cartridge 5-6 full rotations to redistribute the
toner.
• Check the life of all components, refer to GP 2 Machine Status and Reports.
Replace the any component if it is at end of life, refer to the Workcentre® 3025 User
Guide, Section 6 Maintenance, General Care, for detailed instructions on how to replace
components.
Procedure
WARNING
Do not perform repair activities with the power on or electrical power supplied to the
machine. Some machine components contain dangerous electrical voltages that can
result in electrical shock and possible serious injury.
DANGER: Ne pas effectuer de dépannnage avec le contact principal activé ou avec l'ali-
mentation électrique appliquée à la machine. Certains éléments de la machine compor-
tent des tensions électriques dangereuses qui peuvent causer un choc électrique et de
graves blessures.
AVVERTENZA: Non effettuare alcuna riparazione con l'alimentazione elettrica inserita.
Alcuni componenti contengono corrente ad alta tensione che può provocare forti
scosse e gravi ferite.
VORSICHT: Es dürfen erst Reparaturarbeiten durchgeführt werden, wenn das Gerät aus-
geschaltet ist oder der Netzstecker nicht mehr mit der Stromquelle verbunden ist. Ein-
ige Komponenten des Gerätes sind stromführend und können daher zu ernsthaften
Verletzungen oder Stromschlägen führen.
AVISO: No realice reparaciones con la máquina encendida o conectada a la corriente.
Algunos componentes de la máquina contienen voltajes eléctricos peligrosos que
pueden producir una descarga eléctrica y causar daños graves.
Switch Off the Power. Check the contacts on the LVPS / HVPS PWB and the Print Cartridge for
contamination or damage. The contacts are OK.
YN
Replace the Print Cartridge. Refer to the WorkCentre® 3025 User Guide, Section 6 Main-
tenance, General Care, for detailed instructions on how to replace the Toner Cartridges.
Check the Transfer Roller for wear or damage. The Transfer Roller is OK.
YN
Replace the Transfer Roller; (REP 1.17), PL 5.1.
If problem persists, replace the LVPS / HVPS PWB; (REP 1.6), PL 5.1.

Xerox WorkCentre 3025BI Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 20 ppm
Copy Speed	Up to 20 cpm
Copy Resolution	Up to 600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Memory	128 MB
Duplex Printing	Manual
First Page Out	As fast as 8.5 seconds
Paper Input Capacity	150 sheets
Paper Output Capacity	100 sheets
Paper Capacity	150 sheets
Processor Speed	600 MHz
Dimensions	406 x 360 x 257 mm
Weight	7.5 kg
Scan Resolution	600 x 600 dpi
Maximum Document Size	216 x 356 mm
Connectivity	USB, Wi-Fi
Print Resolution	Up to 1200 x 1200 dpi enhanced image quality
Duty Cycle	Up to 15, 000 pages
