Xerox® WorkCentre® 3025 Multifunction Printer Service Manual
IQ12
Image Quality
IQ12 Partial Image Deletions RAP
Areas of the printed image are light or missing entirely on limited areas of the paper (Figure 1).
Initial Actions
Be sure the printer is installed on a level surface.
Procedure
Procedure
• Switch Off the Power.
• Remove the Print Cartridge.
• Rotate the Print Cartridge side to side for 5 to 6 full rotations to redistribute the toner.
• Reinstall and print 10 test copies.
The problem continues.
YN
Go to Call Closeout.
Check the Transfer Roller PL 5.1 for the following:
• Wear or damage.
• The left and right tension springs for damage.
• Be sure all parts are installed correctly.
Figure 1 Image Deletions
To Next Page
