Xerox WorkCentre 3025BI

June 2014
6-12
Xerox® WorkCentre® 3025 Multifunction Printer Service Manual
Product Specifications
General Procedures and Information
NOTE:
Declared yield value in accordance with ISO/IEC 19752.
Depending on the options and job mode used, the Print Cartridge’s lifespan may differ.
When replacing the Print Cartridge, check model number and consumables code. Refer to the
WorkCentre® 3025 User Guide for information regarding ordering consumables.
NOTE:
* Sound Pressure Level, ISO 7779. Configuration tested: basic machine installation, A4 paper,
simplex printing.
** See the rating label on the machine for the correct voltage, frequency (Hz) and type of cur-
rent.
*** If equipped with a power switch.
Table 8 Consumables
Item Specification Approx yield (See note)
Print Cartridge MLT-D111S 1500 images (Ships with 700 page Starter
Print Cartridge)
Table 9 HSFI’s
Item Specification Approx. yield
Fuser Unit JC91-01077A (220V)
JC91-01076A (110V)
30,000 pages
Transfer Roll JC66-02709A 30,000 pages
Pick-Up Roll Assy JC66-00525A 30,000 pages
Friction Pad JC66-00522A 30,000 pages
Table 10 Reliability and Service
Item Specification
Printing Volume (SET AMPV) 75 pages/ month
MPBF 20,000 pages
MTTR 30 minutes
SET Life Cycle 30,000 pages or 5 years (whichever comes first)
Table 11 Environment
Item Specification
Dimension (W x D x H) SET 13.7 x 13.3 x 7.7 in.
348 x 338 x 197 mm
Weight Machine (with
Print cartridge)
• 3025BI: 14.66.lbs. (6.65 Kg)
• 3025NI: 17.64 lbs. (8.0 Kg)
Operating Environment Temperature 50°- 90°F (10°C to 32°C)
Humidity 20% - 80% RH
Acoustic Noise Level*
(Sound Power/Pressure)
Ready mode Less than 26 dB
Print mode Less than 50 dB
Copy mode • Document Glass: Less than 52 dB
• Document Feeder: Less than 51 dB
Scan mode • Document Glass: Less than 52 dB
• Document Glass: Less than 53 dB
Power Rating** 110 Volt models 110-127 VAC
220 Volt models 220-240 VAC
Power Consumption Avg. Operating
Mode
Less than 230 W
Ready Mode Less than 35 W
Power Save
Mode
Less than 1.0 W
Power Off mode Less than 0.45 W (0.1 w***)
Table 11 Environment
Item Specification
