2-4
Xerox® WorkCentre® 3025 Multifunction Printer Service Manual
05-100 / 900 , 05-500
Status Indicator RAPs
05-100 / 900 Paper Jam in Automatic Document Feeder
(ADF) Fault
The machine has detected a paper jam in the Automatiac Document Feeder (3025NI).
BSD-Reference: 5.1B Automatic Document Feeder
Initial Actions
• Remove jammed sheets from the document feeder and paper path. Refer to The Work-
Centre® 3025 User Guide, Section 11 for jam clearance instructions.
• If necessary, power the machine Off then On to clear the fault message.
• Open the top cover of the Document Feeder and check the Feed Roll for contamination or
wear.
Procedure
Inspect the Paper Feed Sensor for damage or contamination. Remove any debris from the
sensor.
Enter Diagnostic (EDC) Mode. Select: [DC330 Component Control, 102 Sensor, Feed
Sens] to test the Paper Feed Sensor. The sensor is OK.
YN
• Check for any open or short circuit and clear any contamination that is present.
• Replace the paper Feed Sensor PWB (REP 1.15), PL 5.3.
Check circuit between the ADF Drive Motor and the Main PWB. The circuit is good.
YN
• Check for an open or short circuit and clear any contamination that is present.
• Replace the ADF Drive Motor PL 3.1.
Check the paper path drives and clear any jammed sheets from the paper path. If problem per-
sists, replace the Main PWB (REP 1.7), PL 1.1.
05-500 Document Feeder Cover Open Fault
The Document Feeder or Document Feeder Top Cover is not securely latched.
BSD-Reference: 5.1A Automatic Document Feeder
Initial Actions
• Close the Document Feeder unit.
• Close the Document Feeder top cover.
Procedure
Check the circuit between the ADF Cover Sensor and the Main PWB. The circuit is good.
YN
• Check for broken or defective wires and that no contamination is present.
• Secure the connection.
• Replace parts as required.
Replace the Main PWB (REP 1.7), PL 1.1.

Xerox WorkCentre 3025BI Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 20 ppm
Copy Speed	Up to 20 cpm
Copy Resolution	Up to 600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Memory	128 MB
Duplex Printing	Manual
First Page Out	As fast as 8.5 seconds
Paper Input Capacity	150 sheets
Paper Output Capacity	100 sheets
Paper Capacity	150 sheets
Processor Speed	600 MHz
Dimensions	406 x 360 x 257 mm
Weight	7.5 kg
Scan Resolution	600 x 600 dpi
Maximum Document Size	216 x 356 mm
Connectivity	USB, Wi-Fi
Print Resolution	Up to 1200 x 1200 dpi enhanced image quality
Duty Cycle	Up to 15, 000 pages
