Machine Components
19
Inside View
No. Component Function
19 Document Cover Close this cover when scanning a document on the Document Glass.
20 Document Glass Place a document here, face down.
21 Fuser Unit Fuses toner onto the paper by applying heat and pressure. Do not touch
this unit. It may become extremely hot.
22 Drum Cartridge Contains toner and photoconductor used to transfer the toner.
23 Duplex Module Copies and prints on both sides of paper.
