Xerox WorkCentre 5222 User Manual

February, 2008
6-10
WorkCentre 5225, 5230
IOT NVM List
Launch Version
General Procedures
742-093 Paper Path Sensor (FINISHER) - 0~63 - Bit0: Fin H-X'port Ent. SENSOR Bit1: Fin H-X'port EXIT SENSOR Bit2: Fin X'port
Ent.SENSOR Bit3: Fin Buffer PATH SENSOR Bit4: COMPILE TRAY EXIT PATH SEN
-
SOR Bit5: Not available Bit6: Top Tray Exit Sensor * The meaning of the bit, 0: Out of
paper, 1: Paper detected. The renewal precision is 10 ms.
760-001 TRAY1 for Plain Paper - LEAD REGI ADJUST-
MENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-002 TRAY2-4,HCF for Plain Paper - LEAD REGI
ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-003 MPT for Plain Paper - LEAD REGI ADJUSTMENT 33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-005 DUP ALL SIZE for Plain Paper - LEAD REGI
ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-006 ALL TRAY - REGI LOOP TIMER 33 0~66 0.363mm Loop increases when Set Value is increased.
760-007 TRAY1 for Plain Paper - REGI LOOP TIMER 33 0~66 0.363mm Loop increases when Set Value is increased.
760-008 TRAY2-4,HCF - REGI LOOP TIMER 33 0~66 0.363mm Loop increases when Set Value is increased.
760-009 MPT for Plain Paper - REGI LOOP TIMER 12 0~66 0.363mm Loop increases when Set Value is increased.
760-010 DUP for Plain Paper - REGI LOOP TIMER 33 0~66 0.363mm Loop increases when Set Value is increased.
760-011 REGI CLUTCH OFF TIMER - ALL TRAY 33 0~66 0.363mm Clutch off is delayed by 2ms when Set Value is increased.
760-012 TOP SIGNAL OFFSET VALUE ADJUSTMENT 0 0~99 0.363mm Not available
760-013 DUP A3 Group - LEAD REGI ADJUSTMENT 10 0~16 0.363mm Image input is delayed when Set Value is increased.
760-014 DUP A4S Group - LEAD REGI ADJUSTMENT 10 0~16 0.363mm Image input is delayed when Set Value is increased.
760-015 DUP A4L Group - LEAD REGI ADJUSTMENT 10 0~16 0.363mm Image input is delayed when Set Value is increased.
760-016 TRAY1 for Heavyweight1 Paper - LEAD REGI
ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-017 TRAY1 for Heavyweight2 Paper - LEAD REGI
ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-018 TRAY2-4,HCFfor Heavyweight1 Paper - LEAD
REGI ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-019 TRAY3-4,HCFfor Heavyweight2 Paper - LEAD
REGI ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-020 MPT for Heavyweight1 Paper - LEAD REGI
ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-021 MPT for Heavyweight2 Paper - LEAD REGI
ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-022 DUP ALL SIZE for Heavyweight1 Paper - LEAD
REGI ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-023 DUP ALL SIZE for Heavyweight2 Paper - LEAD
REGI ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
760-024 TRAY2-4,HCF for Heavyweight1 Paper - REGI
LOOP TIMER
33 0~66 0.363mm Loop increases when Set Value is increased.
760-025 TRAY3-4,HCF for Heavyweight2 Paper - REGI
LOOP TIMER
33 0~66 0.363mm Loop increases when Set Value is increased.
760-026 MPT for Heavyweight1 Paper - REGI LOOP TIMER 24 0~66 0.435mm Loop increases when Set Value is increased.
Table 5 PH
Chain-
Link Name Default Range 1 Count Remarks

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
