Measure the voltage between the DADF PWB (PL 15.3) P786-1 (+) and GND (-) (BSD 5.2
Flag 5).
The voltage is approx. +24VDC.
YN
Replace the DADF PWB (PL 15.3).
Replace the DADF Nudger Motor (PL 15.6). If the problem persists, replace the DADF
PWB (PL 15.3).
Replace the DADF PWB (PL 15.3).
005-286 DADF Feed Out Sensor Failure RAP
During document transport, before the DADF Feed Out Sensor turned Off, the DADF Pre Reg-
istration Sensor turned Off.
Initial Actions
Refer to BSD 5.4.
Procedure
Execute Component Control[005-205]. Actuate the DADF Feed Out Sensor (PL 15.9) with
paper.
The display changes.
YN
Check the connections of P/J769 and P/J758. P/J769 and P/J758 are connected cor-
rectly.
YN
Connect P/J769 and P/J758.
Check the wire between J769 and J758 for an open circuit or a short circuit (BSD 5.4 Flag
13/Flag 14).
The wire between J769 and J758 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P758-1 (+) and GND (-) (BSD 5.4 Flag
14).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P758-3 (+) and GND (-) (BSD 5.4 Flag
13).
Actuate the DADF Feed Out Sensor with paper. The voltage changes.
YN
Replace the DADF Feed Out Sensor (PL 15.9).
Replace the DADF PWB (PL 15.3).
Execute Component Control [005-206]. Actuate the DADF Pre Registration Sensor (PL 15.7)
with paper.
The display changes.
YN
Check the connections of P/J781 and P/J761. P/J781 and P/J761 are connected cor-
rectly.
YN
Connect P/J781 and P/J761.
Check the wire between J781 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
3/Flag 4).
The wire between J781 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-10 (+) and GND (-) (BSD 5.4 Flag
4).
The voltage is approx. +5VDC.
A B
