Xerox WorkCentre 5222 User Manual

February, 2008
6-22
WorkCentre 5225, 5230
IOT NVM List
Launch Version
General Procedures
763-672 Ex_Sheet_Width_Of_Last_Ejected_Sheet - 1, 2
Digit
0 0~99 Width of top sheet in Stacker Tray (0x0000~0xFFFF).
763-672 Ex_Sheet_Width_Of_Last_Ejected_Sheet - 3, 4
Digit
0 0~99
763-672 Ex_Sheet_Width_Of_Last_Ejected_Sheet - 5, 6
Digit
0 0~6
763-673 Ex_Sheet_Length_Of_Last_Ejected_Sheet - 1, 2
Digit
0 0~99 Length of top sheet in Stacker Tray (0x0000~0xFFFF).
763-673 Ex_Sheet_Length_Of_Last_Ejected_Sheet - 3, 4
Digit
0 0~99
763-673 Ex_Sheet_Length_Of_Last_Ejected_Sheet - 5, 6
Digit
0 0~6
763-674 Ex_Sheet_Width_Of_Maximum_Size_Sheet - 1, 2
Digit
0 0~99 Maximum width paper in Stacker Tray (0x0000~0xFFFF).
763-674 Ex_Sheet_Width_Of_Maximum_Size_Sheet - 3, 4
Digit
0 0~99
763-674 Ex_Sheet_Width_Of_Maximum_Size_Sheet - 5, 6
Digit
0 0~6
763-675 Ex_Sheet_Length_Of_Maximum_Size_Sheet - 1, 2
Digit
0 0~99 Maximum length paper in Stacker Tray (0x0000~0xFFFF).
763-675 Ex_Sheet_Length_Of_Maximum_Size_Sheet - 1, 2
Digit
0 0~99
763-675 Ex_Sheet_Length_Of_Maximum_Size_Sheet - 1, 2
Digit
0 0~6
763-677 Ex_Offset_Position 0 0~1 Final offset position. 0: Rear, 1: Front
763-679 NVM_Mix_Stack 0 0~1 Mix Full Stack detect. 0: Not detected, 1: Detected.
763-680 NVM_Puncher_Dust_Count - 1, 2 Digit 0 0~99 The number of sheets required to generate a Puncher Rubbish Full message.
763-680 NVM_Puncher_Dust_Count - 3, 4 Digit 0 0~99
763-680 NVM_Puncher_Dust_Count - 5, 6 Digit 0 0~6
763-684 NVM_Num_Of_Stack_Tray_Sheets - 1, 2 Digit 0 0~99 Number of output sheets for Full detection.
763-684 NVM_Num_Of_Stack_Tray_Sheets - 3, 4 Digit 0 0~99
763-684 NVM_Num_Of_Stack_Tray_Sheets - 5, 6 Digit 0 0~6
763-685 Ex_Stacker_Feed_Count_Lower - 1, 2 Digit 0 0~99 Number of Stacker output sheets (lower value).
Total number of sheets = (upper value) x 65535 + (lower value).
763-685 Ex_Stacker_Feed_Count_Lower - 3, 4 Digit 0 0~99
763-685 Ex_Stacker_Feed_Count_Lower - 5, 6 Digit 0 0~6
763-686 Ex_Stacker_Feed_Count_Upper - 1, 2 Digit 0 0~99 Number of Stacker output sheets (upper value).
Total number of sheets = (upper value) x 65535 + (lower value).
763-686 Ex_Stacker_Feed_Count_Upper - 3, 4 Digit 0 0~99
763-686 Ex_Stacker_Feed_Count_Upper - 5, 6 Digit 0 0~6
763-687 Ex_Stacker_Staple_Count_Lower - 1, 2 Digit 0 0~99 Total staple frequency of Stacker (lower value).
Total staple frequency of Stacker = (upper value) x 65535 + (lower value).
763-687 Ex_Stacker_Staple_Count_Lower - 3, 4 Digit 0 0~99
763-687 Ex_Stacker_Staple_Count_Lower - 5, 6 Digit 0 0~6
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
