February, 2008
6-25
WorkCentre 5225, 5230
IOT NVM List
General Procedures
Launch Version
763-729 NVM_Book_Sub_Pdl_Sol_Strt_Tim 50 0~200 Time from CompileExitSnrOff to energizing Sub Paddle Solenoid (in booklet job mode).
25 (5 with Filter) + NVM_Book_Sub_Pdl_Sol_Strt_Tim = operation start time (initialize
75 [55] ms)
763-730 NVM_Book_R_Stpl_Strt_Tim - 1, 2 Digit 0 5~99 In booklet staple mode, time at which rear staple operation begins.
763-730 NVM_Book_R_Stpl_Strt_Tim - 3, 4 Digit 2 0~5
763-731 NVM_Book_Tray_Down 20 0~40 Sets a pulse count for the Stacker Encoder when the TrayAjust operation was com-
pleted. Limit of input value is “[NVM 763-731] > or = [NVM 763-732]”.
763-732 NVM_Book_Tray_Up1 8 0~40 Sets the limit of upward travel for the first time the Tray goes up after the Booklet Staple
Job Limit of the input value is “[NVM 763-731] > or = [NVM 763-732]”.
763-733 NVM_Book_Adjust_Start_Tim - 1, 2 Digit 0 0~0 1 ms [Unused] Time until beginning of booklet exhaust operation.
763-733 NVM_Book_Adjust_Start_Tim - 3, 4 Digit 0 0~50 1 ms
763-734 NVM_Book_Staple_Move_Escape_Start_Tim - 1, 2
Digit
0 5~99 1 ms [Unused] Booklet Staple Move Motor starts to go back after this time.
763-734 NVM_Book_Staple_Move_Escape_Start_Tim - 3, 4
Digit
5 0~50 1 ms
763-735 NVM_Book_Sml_Sub_Pdl_Sol_Intvl_Tim - 1, 2
Digit
50 0~99 1 ms Effective interval time (off time) to repeat a dragging (Sub Paddle Sol On operating).
Can be set with NVM 736-746 (booklet job and length of paper < 364.0 [B4]).
763-735 NVM_Book_Sml_Sub_Pdl_Sol_Intvl_Tim - 3, 4
Digit
0 0~2 1 ms
763-736 NVM_Book_Lrg_Sub_Pdl_Sol_Intvl_Tim - 1, 2 Digit 50 0~99 1 ms Effective interval time (off time) to repeat a dragging (Sub Paddle Sol On operating).
Can be set with NVM 736-746 (booklet job and length of paper < 364.0 [B4]).
763-736 NVM_Book_Lrg_Sub_Pdl_Sol_Intvl_Tim - 3, 4 Digit 0 0~2 1 ms
763-737 [Unused] NVM_Set_Clmp_Book_Off_Tim 100 0~200 [Unused] The amount of time to retain the status of Set Clamp Goback when a booklet
uses large size paper. Usage: 170 + NVM_Set_Clmp_Book_Escape_Keep_Tim (initial
-
ize 270 ms).
763-738 [Unused]
NVM_Set_Clmp_Book_Escape_Keep_Tim
100 0~200 [Unused] The amount of time the Clutch is on to operate the Set Clamp when outputting
large-size booklets. Usage: 185 + NVM_Set_Clmp_Book_Clon_Tim (initialize 285 ms).
763-739 NVM_Set_Clmp_Book_Eject_Rev_Pls - 1, 2 Digit 20 0~99 The amount of time the Eject Motor operates in reverse when outputting small-size
(paper size < 322 mm) booklets.
Usage: [1207.4 - (2x paper length) + 50] - 529 -120 + NVM (Default: 134 pulses on
A4S).
763-739 NVM_Set_Clmp_Book_Eject_Rev_Pls - 3, 4 Digit 1 0~3
763-740 NVM_Book_Eject_Border_Sheet_Num_S 5 2~25 The number of sheets of the Eject Motor speed switch when outputting small-size
(paper length = or < 330 mm) booklets.
763-741 NVM_Book_Eject_Exit_Speed_Less_S 3 1~4 When outputting small-size booklets, if the Eject Motor speed switch count is less than
the set value (NVM 763-740), the exit speed of the Eject Motor is set as follows:
1 = low speed, 2 = middle speed, 3 = high speed, 4 = super high speed.
763-742 NVM_Book_Eject_Exit_Speed_More_S 3 1~4 When outputting small-size (paper length = or < 330 mm) booklets, if the Eject Motor
speed switch count is more than the set value (NVM 763-740), the exit speed of the
Eject Motor is set as follows:
1 = low speed, 2 = middle speed, 3 = high speed, 4 = super high speed.
763-743 NVM_Book_Eject_Border_Sheet_Num_L 5 2~25 The number of sheets of the Eject Motor speed switch when outputting large-size
(paper length > 330 mm) booklets.
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks
