February, 2008
6-27
WorkCentre 5225, 5230
IOT NVM List
General Procedures
Launch Version
763-760 NVM_Book_Traydown_Setcount_L1 4 1~15 The number of increments the Tray moves down after a booklet staple set is outputted.
Large size: Each increment ~ 3 copies.
763-761 NVM_Book_Traydown_Setcount_L2 2 1~15 The number of increments the Tray moves down after a booklet staple set is outputted.
Large size: Each increment 4 ~ 7 copies.
763-762 NVM_Book_Traydown_Setcount_L3 3 1~15 The number of increments the Tray moves down after a booklet staple set is outputted.
Large size: Each increment 8 ~ 10 copies.
763-763 NVM_Book_Traydown_Setcount_L4 1 1~15 The number of increments the Tray moves down after a booklet staple set is outputted.
Large size: Each increment 11 ~ copies.
763-764 NVM_Book_Traydown_Addpulse_S1 2 1~15 Number of pulses added to Tray Down increment. Small size: ~ 3 copies.
763-765 NVM_Book_Traydown_Addpulse_S2 3 1~15 Number of pulses added to Tray Down increment. Small size: 4 ~ 7 copies.
763-766 NVM_Book_Traydown_Addpulse_S3 2 1~15 Number of pulses added to Tray Down increment. Small size: 8 ~ 10 copies.
763-767 NVM_Book_Traydown_Addpulse_S4 1 1~15 Number of pulses added to Tray Down increment. Small size: 11 ~ copies.
763-768 NVM_Book_Traydown_Addpulse_L1 2 1~15 Number of pulses added to Tray Down increment. Large size: ~ 3 copies.
763-769 NVM_Book_Traydown_Addpulse_L2 1 1~15 Number of pulses added to Tray Down increment. Large size: 4 ~ 7 copies.
763-770 NVM_Num_Of_Ejected_Booklet_Staple_Set 0 0~255 The saddle-stapled number of copies outputted to the Booklet Tray.
763-771 NVM_Book_Traydown_Addpulse_L3 2 0~15 Number of pulses added to Tray Down increment. Large size: 8 ~ 10 copies.
763-772 NVM_Book_Traydown_Addpulse_L4 1 0~15 Number of pulses added to Tray Down increment. Large size: 11 ~ copies.
763-773 NVM_Puncher_Full_Count_Num_233 - 1, 2 Digit 50 0~99 The number of sheets required to generate a Puncher Rubbish Full message (2-3 hole
punch). Effective when NVM 763-605 is 5.
763-773 NVM_Puncher_Full_Count_Num_233 - 3, 4 Digit 7 0~15
763-774 NVM_Puncher_Full_Count_Num_SW4 - 1, 2 Digit 75 0~99 The number of sheets required to generate a Puncher Rubbish Full message (6 hole
punch). Effective when NVM 763-605 is 5.
763-774 NVM_Puncher_Full_Count_Num_SW4 - 3, 4 Digit 3 0~15
763-775 NVM_Puncher_Near_Count_Num_233 - 1, 2 Digit 0 0~99 The number of sheets required to generate a Puncher Rubbish warning (2-3 hole
punch). Effective when NVM 763-605 is 2 or 3.
763-775 NVM_Puncher_Near_Count_Num_233 - 3, 4 Digit 5 0~15
763-776 NVM_Puncher_Near_Count_Num_SW4 - 1, 2 Digit 50 0~99 The number of sheets required to generate a Puncher Rubbish warning (6 hole punch).
Effective when NVM 763-605 is 6.
763-776 NVM_Puncher_Near_Count_Num_SW4 - 3, 4 Digit 2 0~15
763-777 NVM_Stk_Eject_Stpl_Exit_Speed_S1 5 1~6 Exit speed of the Eject Motor for small size paper (paper length < Letter L) for sheets 1-
9 during front/rear staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-778 NVM_Stk_Eject_Stpl_Exit_Speed_S2 5 1~6 Exit speed of the Eject Motor for small size paper (paper length < Letter L) for sheets
10-29 during front/rear staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-779 NVM_Stk_Eject_Stpl_Exit_Speed_S3 5 1~6 Exit speed of the Eject Motor for small size paper (paper length < Letter L) for sheets 30
and above during front/rear staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-780 NVM_Stk_Eject_Stpl_Exit_Speed_M1 6 1~6 Exit speed of the Eject Motor for medium size paper (paper length > Letter L~13 inches)
for sheets 9 and above during front/rear staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks
