February, 2008
6-29
WorkCentre 5225, 5230
IOT NVM List
General Procedures
Launch Version
Chain 764-xxx Finisher
763-791 NVM_Stk_Eject_Dual_Stpl_Exit_Speed_M2 1 1~6 Exit speed of the Eject Motor for medium size paper (paper length > Letter L~13 inches)
for sheets 10-29 during dual staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-792 NVM_Stk_Eject_Dual_Stpl_Exit_Speed_M3 1 1~6 Exit speed of the Eject Motor for medium size paper (paper length > Letter L~13 inches)
for sheets 1-30 during dual staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-793 NVM_Stk_Eject_Dual_Stpl_Exit_Speed_L 6 1~6 Exit speed of the Eject Motor for large size paper (paper length = or > 13 inches) during
dual staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-797 NVM_Write_Address 0 0~3
763-798 NVM_Write_Count_Lower - 1, 2 Digit 0 0~99 NVM write frequency (lower value).
Total NVM write frequency = (upper value) x 65535 + (lower value)
763-798 NVM_Write_Count_Lower - 3, 4 Digit 0 0~99
763-798 NVM_Write_Count_Lower - 5, 6 Digit 0 0~6
763-799 NVM_Write_Count_Upper - 1, 2 Digit 0 0~99 NVM write frequency (upper value).
Total NVM write frequency = (upper value) x 65535 + (lower value)
763-799 NVM_Write_Count_Upper - 3, 4 Digit 0 0~99
763-799 NVM_Write_Count_Upper - 5, 6 Digit 0 0~6
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks
Table 14 Finisher
Chain-link Name Default Range 1 Count Remarks
764-100 Mix Stack Enable/Disable 0 0~1 - 0: Enable (mix size stack is detected)
1: Disable (mix size stack is not detected)
764-101 Maximum Set Count 50 0~100 - Maximum number of document sets that can be stacked (A-Finisher)
764-102 Maximum Compile Sheet Count for Staple 50 0~100 - Maximum volume of large-sized and unstapled paper that can be compiled
764-103 Maximum Compile Sheet Count for Un-Staple/Big
paper size
25 10~100 - Maximum volume of large-sized and unstapled paper that can be compiled
764-104 Maximum Compile Sheet Count for Un-Staple/
Small paper size
50 10~100 - Maximum volume of small-sized and unstapled paper that can be compiled
764-112 Sleep Mode Recovery Indicate 0 0~1 - Not available
764-120 Maximum Set Count(A-fin) 30 30~300 Maximum number of document sets that can be stacked (A-Fin)
764-121 Maximum Compile Sheet Count(Staple/Big) 30 10~50 Maximum volume of large-sized and stapled paper that can be compiled. (Paper length
is more than 297.0 mm) (A-Fin)
764-122 Maximum Compile Sheet Count(Staple/Small) 50 10~70 Maximum volume of small-sized and stapled paper that can be compiled. (Paper length
is 297.0 mm or less) (A-Fin)
764-123 Max Compile Sheet Count(Un-Staple/Plain Big) 1 1~25 Maximum volume of large-sized and unstapled plain paper that can be compiled.
(Paper length is more than 297.0 mm) (A-Fin)
To Next Page
