February, 2008
6-32
WorkCentre 5225, 5230
IIT NVM List
Launch Version
General Procedures
Chain 710-xxx DADF
Table 1 DADF
Chain-Link Content Default Range Meaning
710-501 Fax Document Size Detection Method for DADF 0 0~1 Switches detection methods when Fax Document Size Detection is specified in DADF mode. 0: A/B
series, 1: Inch series
710-551 JAM Bypass 0 0~1 0: Do not bypass, 1: Bypass. Also applies to CVT mode.
710-556 8.5”x11” LEF Threshold 2093 1993~2193 Threshold value for distinguishing 8.5”x11” LEF from 8”x10” LEF
710-557 B5 SEF/8”x10” SEF Switching 0 0~1 0: B5 SEF (FX/XE/AP), 1: 8”x10” SEF (XC)
710-558 11”x15” SEF/8-k Switching (for AP market) 0 0~1 0: 11”x15” SEF, 1: 8 k
710-559 FS MAX Value 2970 1297~3070 DADF document size detection table for registration by customers
710-560 FS MIN Value 2970 1297~3070 DADF document size detection table for registration by customers
710-561 SS MAX Value 2100 1297~4418 DADF document size detection table for registration by customers
710-562 SS MIN Value 2100 1297~4418 DADF document size detection table for registration by customers
710-563 Document Size 8 3~20 DADF document size detection table for registration by customers
710-564 Document Process Direction 0 0~1 DADF document size detection table for registration by customers
710-565 DADF Document Size Detection Table 0 0~1 DADF document size detection table for registration by customers
710-566 Lead Registration Correction for Side 2 of S-sized
documents
250 217~283 Lead registration correction value for Side 2 of S-sized documents. (Unit = step.) S-sized paper with
a length between 131.7mm and 158.0mm in the slow scan direction.
710-567 Lead Registration Correction for Side 2 of M-sized
documents
250 217~283 Lead registration correction value for Side 2 of M-sized documents. (Unit = step.) M-sized paper with
a length between 158.1mm and 245.9mm in the slow scan direction.
710-568 Lead Registration Correction for Side 2 of L-sized
documents
250 217~283 Lead registration correction value for Side 2 of L-sized documents. (Unit = step.) L-sized paper with
a length between 246.0mm and 460.0mm in the slow scan direction.
710-600 Size Mismatch Jam Detection Setting (Applicable
only in Simplex mode)
1 1~2 1: Size Mismatch Jam Detection On 2: Size Mismatch Jam Detection Off
710-601 Alternate Size Set 1 1 1~2 PF1: Switches between 8.5x13 SEF and 8.46x12.4 SEF No-Mix/Size-Mix: Inch 13
1: 8.5x13 SEF, 2: 8.46x12.4 SEF
710-602 Alternate Size Set 2 1 1~2 PF1: Switches between 8.5x14 SEF and 8.46x12.4 SEF No-Mix/Size-Mix: Inch 14
1: 8.5x14 SEF, 2: 8.46x12.4 SEF
710-603 Alternate Size Set3 0 0~2 PF1: Switches between 11x15S and 11x17S. No-Mix: mm, No-Mix/Size-Mix: Inch13/Inch14,0:
Default,1: 11x17S,2: 11x15S PF2: Switches between 11x15S and 11x17S. No-Mix: mm/Inch13/
Inch14, Size-Mix: Inch13/Inch14,0: Default,1: 11x17S,2: 11x15S
710-604 Alternate Size Set4 0 0~2 PF1: Switches between 8.46x12.4S, 8.5x13S and 8.5x14S. No-Mix/Size-Mix: mm,0: Default,1:
8.5x13S,2: 8.5x14S PF2: Switches between 8.5x13S and 8.5x14S. No-Mix/Size-Mix: mm Initial
value: 2,0: Default,1: 8.5x13S,2: 8.5x14S
710-605 Alternate Size Set5 0 0~2 PF1: Switches between BS5 and 16KS. No-Mix: mm,0: Default,1: B5S,2: 16KS PF2: Switches
between B5S and 16KS. No-Mix/Size-Mix: mm 0: Default,1: B5S, 2: 16KS
710-606 Alternate Size Set6 0 0~3 PF1: Switches between 8x10S, 8x10.5S and 8.5x11S. Size-Mix: Inch13/Inch14,0: Default,1:
8.5x11S,2: 8x10S,3: 8x10.5S PF2: Switches between 8x10S, 8x10.5S and 8.5x11S. Size-Mix:
Inch13/Inch14,0: Default,1: 8.5x11S,2: 8x10S,3: 8x10.5S
710-607 Alternate Size Set7 0 0~3 PF1: Switches between 8x10L, 8x10.5L and 8.5x11L. Size-Mix: Inch13/Inch14,0: Default,1:
8.5x11L,2: 8x10L,3: 8x10.5L PF2: Switches between 8x10L, 8x10.5L and 8.5x11L. Size-Mix: Inch13/
Inch14,0: Default,1: 8.5x11L,2: 8x10L,3: 8x10.5L
710-608 Alternate Size Set8 0 0~3 PF2: Switches between B4S, 8KS, 11x15S and 11x17S. Size-Mix: mm,0: Default,1: B4S,2: 8KS 3:
11x15S 4: 11x17S PF2: Switches between B4S, 8KS and 11x17S. Size-Mix: mm,0: Default,1:
B4S,2: 8KS 3: 11x17S PF2 setting range is 0~3.

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
