February, 2008
6-34
WorkCentre 5225, 5230
IIT NVM List
Launch Version
General Procedures
715-064 CVT FS Offset Side1-5 (214.9-215.9) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-065 CVT FS Offset Side2-5 (214.9-215.9) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-066 CVT FS Offset Side1-6 (254-257) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-067 CVT FS Offset Side2-6 (254-257) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-068 CVT FS Offset Side1-7 (266.7-267) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-069 CVT FS Offset Side2-7 (266.7-267) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-070 CVT FS Offset Side1-8 (279.4) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-071 CVT FS Offset Side2-8 (279.4) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-072 CVT FS Offset Side1-9 (297) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-073 CVT FS Offset Side2-9 (297) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-074 CVT FS Offset Side3-1 (139.7-148) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-075 CVT FS Offset Side4-1 (139.7-148) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-076 CVT FS Offset Side3-2 (182-194) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-077 CVT FS Offset Side4-2 (182-194) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-078 CVT FS Offset Side3-3 (203.2) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-079 CVT FS Offset Side4-3 (203.2) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-080 CVT FS Offset Side3-4 (210) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-081 CVT FS Offset Side4-4 (210) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-082 CVT FS Offset Side3-5 (214.9-215.9) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-083 CVT FS Offset Side4-5 (214.9-215.9) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-084 CVT FS Offset Side3-6 (254-257) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-085 CVT FS Offset Side4-6 (254-257) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-086 CVT FS Offset Side3-7 (266.7-267) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-087 CVT FS Offset Side4-7 (266.7-267) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-088 CVT FS Offset Side3-8 (279.4) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-089 CVT FS Offset Side4-8 (279.4) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-090 CVT FS Offset Side3-9 (297) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-091 CVT FS Offset Side4-9 (297) 120 0~240 Fast Scan Direction Regi Correction Value (2dot/increment) in CVT. Factory Settings
715-092 WREF_ADJ_R 140 70-255
715-093 WREF_ADJ_G 140 70-255
715-094 WREF_ADJ_B 140 70-255
715-095 WREF_ADJ__BWX 140 70~255 BW-X W-Ref correction coefficient, Factory Settings
715-096 WREF_ADJ__BWY 140 70~255 BW-Y W-Ref correction coefficient, Factory Settings
715-102 WREF_Offset_R 63 0~127
715-103 WREF_Offset_G 63 0~127
715-104 WREF_Offset_B 63 0~127
715-105 WREF_ADJ_BW (Individual Paper) 63 0~127 BW W-Ref correction coefficient for each individual paper type.
715-106 IIT Paper Code 0 0~8 0: NVM uses coefficient for each individual paper type 1: J paper, 2: P paper, 3: C2 paper, 4:
Green100 paper, 5: Digital Color Xpression, 6: Color Tech+, 7: Xerox4200 paper, 8: Xerox Business
715-107 Nut_Angle_Front 990 0~1980 Light Axis Front Nut rotation angle (990~1980: Right revolution angle, 0~990: Left revolution angle)
715-108 Nut_Angle_Rear 990 0~1980 Light Axis Rear Nut rotation angle (990~1980: Right revolution angle, 0~990: Left revolution angle)
Table 2 IISS
