Xerox WorkCentre 5222 User Manual

February, 2008
6-36
WorkCentre 5225, 5230
IIT NVM List
Launch Version
General Procedures
715-310 A3/11x17 Detection 0 0~3 0: Table default 1: A3SEF 2: This value is for design test. Performance is not guaranteed. 3: A3SEF,
11x17SEF
715-311 A4/8.5x11 Detection 0 0~3 0: Table default 1: A4LEF 2: This value is for design test. Performance is not guaranteed. 3:
8.5x11LEF, A4LEF
715-312 A6S Threshold 90 50~110 Changes the threshold value in the fast scan direction between non-standard size paper, postcard
SEF, and A6 SEF. When values outside the setting range (50~100) are set, the threshold value in
the fast scan direction is 90mm. 50 ~ 100mm in 1mm increments.
715-344 Original Size Detection, Platen Background
Countermeasure for Dirt
0 0~1 0: Detection by 4 registers 1: Detection by 3 registers (countermeasure for dirt)
715-345 GCO/TFX Size Switch 1 0~1 0: GCO (16K/8K=270x195/270x390) 1: TFX (16K/8K=267x194/267x388)
715-346 B4/8K Fast Scan Threshold Value Setting 3 0~6 0: 256mm, 1: 258mm, 2: 260mm, 3: 262mm, 4: 264mm, 5: 266mm, 6: 268mm
715-347 8K/11x17SEF Fast Scan Threshold Value Setting 3 0~6 0: 269mm, 1: 271mm, 2: 273mm, 3: 275mm, 4: 277mm, 5: 279mm, 6: 281mm
715-349 B6/5x7 Detection 0 0~2 0: Table default 1: B6SEF 2: 5x7SEF
715-362 FL_CHK_NG_Count 0 0~65535 Lamp Check NG Count (Reset when lamp is replaced)
715-363 FL_CHK_NG_Data 0 0~1023 Data obtained when Lamp Check Fails (Read G Write data compared at checking)
715-418 AOCerr 0 0~255 Number of times the AOC flow has ended abnormally
715-550 TP_BW_Copy BGR-AE-Level 0 0~4095 Removal amount is “the value (0 to 15) X 3” (8-bit conversion). (For 10-bit conversion, “the value [0
to 15] X 12”.) Last 0 to 3 bits: Platen, 4 to 7 bits: CVT or machines with DADF, 8 to 11 bits: CVT or
machines with DADF (duplex copy)
715-551 TP_CL_Copy BGR-AE-Level 0 0~4095 Removal amount is “the value (0 to 15) X 3” (8-bit conversion). (For 10-bit conversion, “the value [0
to 15] X 12”.) Last 0 to 3 bits: Platen, 4 to 7 bits: CVT or machines with DADF, 8 to 11 bits: CVT or
machines with DADF (duplex copy)
715-552 TX_BW_Copy BGR-AE-Level 0 0~4095 Removal amount is “the value (0 to 15) X 3” (8-bit conversion). (For 10-bit conversion, “the value [0
to 15] X 12”.) Last 0 to 3 bits: Platen, 4 to 7 bits: CVT or machines with DADF, 8 to 11 bits: CVT or
machines with DADF (duplex copy)
715-553 TX_CL_Copy BGR-AE-Level 0 0~4095 Removal amount is “the value (0 to 15) X 3” (8-bit conversion). (For 10-bit conversion, “the value [0
to 15] X 12”.) Last 0 to 3 bits: Platen, 4 to 7 bits: CVT or machines with DADF, 8 to 11 bits: CVT or
machines with DADF (duplex copy)
715-554 TP_BW_Contone BGR-AE-Level 0 0~4095 Removal amount is “the value (0 to 15) X 3” (8-bit conversion). (For 10-bit conversion, “the value [0
to 15] X 12”.) Last 0 to 3 bits: Platen, 4 to 7 bits: CVT or machines with DADF, 8 to 11 bits: CVT or
machines with DADF (duplex copy)
715-555 TP_CL_Contone BGR-AE-Level 0 0~4095 Removal amount is “the value (0 to 15) X 3” (8-bit conversion). (For 10-bit conversion, “the value [0
to 15] X 12”.) Last 0 to 3 bits: Platen, 4 to 7 bits: CVT or machines with DADF, 8 to 11 bits: CVT or
machines with DADF (duplex copy)
715-560 BWPG Density 128 0~255 Solid PG density of the whole page (0: Black)
715-600 AE1 FS External Area 255 0~65535 High Speed AE/Fast Scan Direction undetected area INSTV At SMPST, SMPED setting
715-601 AE2 FS External Area 255 0~65535 High Speed AE/Fast Scan Direction undetected area INSTV At HAEFST, HAEFSE setting
715-602 AE3 FS External Area 255 0~65535 High Speed AE/Fast Scan Direction undetected area INSTV At MAEFST, MAEFSE setting (* Area
used as detection area is used for PreIPS noise removal as well)
715-603 AE4 FS External Area 255 0~65535 High Speed AE/Fast Scan Direction undetected area INSTV At NAEFST, NAEFSE setting
715-604 Line to Fix Variation 60 0~65535 High Speed AE/Slow Scan Direction variable fixed position/NCON Slow Scan Edge AE Detection
Amount (0.16mm increments)
715-605 HAE Line to Fix Variation 240 0~65535 End position for AE in the slow scan direction. Width in the slow scan direction for detecting back-
ground density with RAE. HAESSE
Table 2 IISS
Chain-Link Content Default Range Meaning

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
